Autoranging Bench Top Multimeter with 53000 Counts MS8050
Features of Top Multimeter MS8050
* Display VFD: 53000 counts
* Auto Ranging: yes
* Manual Ranging: yes
* PC: PC analysis software
* Voltage & Current AC+DC Measurement: mV/V/μA/mA/A
* True RMS: For AC voltage and AC current
* dBm Measurement: 4Ω/8Ω/16Ω/32Ω/50Ω/75Ω/93Ω/110Ω/125Ω/135Ω/150Ω/200Ω/
250Ω/300Ω/500Ω/600Ω/800Ω/900Ω/1000Ω/1200Ω
* Relative measurement: yes
* Didoe: 2.7V
* Continuity Buzzer: <50Ω
* Max/Min/Max-Min/AVG: yes
* Data hold: yes
* Data Logging: 30 groups
* VFD Display: yes
* USB interface: window OS
Specifications of Top Multimeter MS8050
* DC Voltage
- Range: 50mV/500mV/5V/50V/500V/1000V; Accuracy: +/-(0.03%+6)
* AC Voltage
- Range: 50mV/500mV/5V/50V/500V/1000V; Accuracy: +/-(0.5%+40)
* DC Current
- Range: 500μA/5mA/50mA/500mA; Accuracy:+/-(0.15%+10)
- Range: 5A/10A; Accuracy: +/-(0.5%+10)
* AC Current
- Range: 500μA/5mA/50mA/500mA; Accuracy:+/-(0.75%+10)
- Range: 5A/10A; Accuracy: +/-(1.0%+10)
* Resistance
- Range: 500Ω/5KΩ/50KΩ/500KΩ/5MΩ; Accuracy:+/-(0.1%+5)
- Range: 50MΩ; Accuracy: +/-(0.5%+10)
* Capacitance
- Range: 50nF/500nF/5μF/50μF; Accuracy: +/-(1%+10)
- Range: 500μF/5000μF; Accuracy: +/-(2%+10)
* Logic Frequency
- Range: 5Hz~2MHz; Accuracy: +/-(0.006%+4)
* Duty cycle
- Range: 10%~90%; Accuracy: +/-1.0%
* Linear Frequency
- Range: 5Hz~200kHz; Accuracy: +/-(0.006%+4)
* Power supply: 220V/110V AC
* Product size: 320mm x 255mm x 106mm /12.6" x 10" x 4.17"
* Product weight: 3112g/6.85lb
* Safety rating: CE CAT. II 1000V RoHS
