CNC Lathe Machine Ck6150t CNC Machine Tool with CE
| Price: |
US $ 10000-20000/Set |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Set |
| Pay Type: |
L/C,T/T,Western Union |
CK6150T Large hole CNC lathe
The main technical parameters and configuration
| Item | Technical parameters |
| CK6150T |
| Maximum workpiece swing diameter over bed | 500mm |
| Spindle center to bed rail distance | 250mm |
| Maximum workpiece swing diameter over skateboard | 270mm |
| Maximum distance between centers | 1000mm |
| Turret cross travel (X-axis) | 290mm |
| Spindle bore maximum diameter | 140mm |
| Spindle speed mode | Frequency stepless speed |
| Spindle speed range | 70-800r/min |
| Bed rail width | 400mm |
| Diameter of tailstock quill | 75mm |
| Maximum stroke of tailstock sleeve | 150mm |
| Taper of tailstock sleeve | M5 |
| Automatic lubrication interval time | 12min/ |
| Rapid traverse rate | X:4m/min Z:6m/min |
| X / Z axis repeatability positioning accuracy | 0.012/0.016mm |
| Main motor | 7.5KW |
| Cooling pump power | 95W |
| Large hole jaw chuck | Φ380 |
Standard configuration:
1. Frequency stepless speed
2. Manually chuck;
3. Four-station electric turret;
4. Servo feed drive system;
5. Automatic lubrication system;
6. Cooling system;
7. Manual tailstock;
8. CNC system (GSK980);
Optional configuration:
1. Six-station electric turret ;
2. CNC (Fanuc, Siemens, KND,etc.);
3. Big bore front pneumatic chuck.
| Prod Model: |
CK6150T |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Maximum Workpiece Swing Dia. Over Bed: |
500mm |
| Spindle Center To Bed Rail Distance: |
250mm |
| Maximum Workpiece Swing Dia. Over Pallet: |
270mm |
| Maximum Distance Between Centers: |
1000mm |
| Turret Cross Travel (X-Axis): |
290mm |
| Spindle Bore Maximum Diameter: |
140mm |
| Spindle Speed Mode: |
Frequency Stepless Speed |
| Spindle Speed Range: |
70-800r/Min |
| Bed Rail Width: |
400mm |
| Diameter Of Tailstock Quill: |
75mm |
| Type: |
Horizontal Lathe |
| Processing Accessory: |
Chuck CNC Lathe |
| Tool Holder: |
Single-tool Holder CNC Lathe |
| Power Source: |
Pneumatic |
| Controlling Mode: |
CNC |
| Automatic Grade: |
Automatic |
| Setting Mode: |
Floor-type |
| Precision: |
High Precision |
Taian Haishu Machinery Co., Ltd. is a professional production mechatronic product, collection development, manufacture, sales of high-tech enterprises. Company under the two divisions: One is the CNC machine tools division, the leading product is the "haishu" brand of CNC lathes and machining centers; One is the test equipment division, the leading product is "Taishanhaite" brand common rail test bench and injectoin pump, fuel injector test bench. Founded in March 2001, covers an area of 15000m2, building area of 8000m2, fixed assets 16 million yuan(RMB), has passedISO9001: 2008 international quality management system certification and European CE certification. The company has strong technical force, with a group of young and promising in the machine and test rig design and manufacture, electrical design and application of CNC technology and software development expertise and skills. Advanced 2D and 3D CAD, document management to achieve the PDM. Product innovation, Equipment CNC, Management information, Which has become the industry technology leader.
The company has a Ministry of Internal Trade and the Ministry of Foreign Trade, with independent import and export rights. The products are sold to more than 20 domestic provinces, cities and autonomous regions, and exported to 30 countries including: USA, Britain, Germany, Italy, Turkey, Greece, Sweden, Bulgaria, Romania, Denmark, Czechoslovakia, Lebanon, New Zealand, Australia, Peru, Ecuador, Colombia, Chile, Russia, Belarus, Lithuania, Bahrain, Korea, India, Indonesia, Malaysia, Iran, Thailand, Philippines, Mongolia.
Main products: 1. Horizontal flat bed CNC lathe, 2. Horizontal slant bed CNC lathe, 3. Vertical CNC lathe, 4. CNC turning center, 5. CNC pipe thread lathe, 6. CNC milling machine, 7. CNC machining center, 8. CNC grinding machine.
Characteristic services: Bear machining overall program design and implementation. Include: Site planning, equipment layout, tooling tool provide, processing program design, remote operation monitoring. Machine shop to achieve unmanned.
The company has many years of experience in development and manufacturing of CNC machine tools, "technology innovation, integrity service" as a business philosophy, with new and old customers at home and abroad in close cooperation and common development.
