Boke Cutting Tools Co., Limited >> CNC Machine Tungsten Carbide Cutting Tools

CNC Machine Tungsten Carbide Cutting Tools

Name: CNC Machine Tungsten Carbide Cutting Tools
Brand: China-Manufacturer-Directory.com
SKU: 723136895
Availability: InStock
Rating: 4.7 (51 reviews)

Supplier:	Boke Cutting Tools Co., Limited
Price:	Negotiable/Piece
Min Order:	5/Piece
Quantity::
Trade Terms:	FOB,CFR,EXW

Product Specifications

Prod Model:	CNC Machine Cutting tools
Markets:	North America,South America,Eastern Europe,Southeast Asia,Oceania,Mid East,Eastern Asia,Western Europe
Mm/Inch:	1mm-25mm/ 1/16"-3/4"
Process Usage:	Metal-Cutting CNC Machine Tools
Movement Method:	Contour Control
Control Method:	Closed-Loop Control
Numerical Control:	NC
Performance Classification:	High-End CNC Machine Tools

Product Description

Specifications

1. CNC Machine cutting tools

2. HRC45/HRC55/HRC60/HRC65
3. virious carbide end mils including square, ball nose, aluminium, corner radius
roughing, micro and long neck from 1T to 6T
4. Shank can process upon customer-made

Speciafications

Chemical Composition: 8%-10%Co-WC
Physical and Machinal properties: Density: 14.40-14.65g/cm3 Hardness: 91-93 HRA Flexural Strength: 3200-4000N/mm2
Organizational Structure: WC mean grain size: 0.5-0.6um
Corresponds to International Standards: K20-K30, K20-K40
Suitable for: Machining of cast iron, nonferrous alloy, nonferrous metals, fireproof alloy, Titanium alloy, alloy steel, carbon steel and other non-metallic. It has suitable for finishing processing the grooves and side. Meanwhile, it can be processing in high speed and high efficiency which the material HRC>60

2. Quality assure

All our products not only using the well-known raw materials manufacturing from home and aboard, but also we have a series of production and processing equipments and precision testing equipment to guaranteed quality.

1. Raw Materials

Overseas

GUHRING material imported from Germany.
WF25 material imported from Taiwan
TAEGUTEC material imported from Korea.

Domestic

The domestic material we purchased from Zhuzhou, and Zigong the well-known brands.

3. Testing Equipment

GUHRING detecting instrument imported from Germany.
MITUTOYO detecting instrument imported from Japan.
PARLEC tools presetter imported from USA.

3. Packing & Delivery

1. Packing Detail

One plastic pipe pack one piece, 10 pieces per group.

2. Use the air bubble paper to encase the plastic paper.

3. Put the goods encased with air bubble paper into the carton.

4. Other packing will be accept according to your needs.

(Order No)	Cutting	Flute	Shank	A.0.L
(Order No)	d	l	D	L
1.0×3×4D×50L×4F	1	3	4	50
1.5×4×4D×50L×4F	1.5	4	4	50
2.0×6×4D×50L×4F	2	6	4	50
2.5×8×4D×50L×4F	2.5	8	4	50
3.0×8×4D×50L×4F	3	8	4	50
3.5×10×4D×50L×4F	3.5	10	4	50
4.0×11×4D×50L×4F	4	11	4	50
3.0× 8×6D×50L×4F	3	8	6	50
3.5×10×6D×50L×4F	3.5	10	6	50
4.0×11×6D×50L×4F	4	11	6	50
4.5×13×6D×50L×4F	4.5	13	6	50
5.0×13×6D×50L×4F	5	13	6	50
5.5×13×6D×50L×4F	5.5	13	6	50
6.0×15×6D×50L×4F	6	15	6	50
7.0×16×8D×60L×4F	7	16	8	60
8.0 ×20×8D×60L×4F	8	20	8	60
9 ×20×10D×75L×4F	9	20	10	75
10×25×10D×75L×4F	10	25	10	75
11×25×12D×75L×4F	11	25	12	75
12×30×12D×75L×4F	12	30	12	75
14×35×14D×100L×4F	14	35	14	100
16×40×16D×100L×4F	16	40	16	100
18×45×18D×100L×4F	18	40	18	100
20×45×20D×100L×4F	20	45	20	100

We are a professional manufacturer of good quality carbide cutting tools, with an experienced design team. Our company was founded in 2001.

At present, we use the best six-axis CNC grinding equipment from Germany to produce high-speed carbide end mills, which is suitable for cutting highly hard and soft metal.

It is our business policy to strive for the development and innovation of carbide end mills, provide high-quality products, and offer custom designs for meeting your various needs. We have gotten customer' S support and affirmation since we were established.

In order to allow more customers to know us, we are moving toward internationalization. With the combination of sophisticated technology and modern network marketing, we provide more and better service.

Welcome to our company. We will do our best to be professional in the precision cutting tool production, and create the best results for you.

We willstrive to provide you with high quality products and quality service, We can also accept any kinds of payment terms, such as T/T, Western Union, L/C, OA, D/P, Escrow etc.

"Quality first, Customer first" is our orientation, we sincerely invite you to our company for the bright future. You are welcome to contact us for future friendly business relationships so as to achieve mutual benefit.

Do not be hesitate to contact us if you have interest in our goods, because of different countries in different time difference, you may met businessmen are not online or out, making your enquiry in our mails would be highly appreciated and we will respond you soon.
