Compressed Earth Blocks Machine

Our compressed earth blocks machine is the core machine used for producing blocks/bricks.
The technology is introduced from German Hess. This machine is automatic and multi-functional. It can produce large varieties and various sizes of products. It can produce concrete blocks, bricks, hollow block, insulated block, solid bricks, paving slabs, interlocking pavers, paving stone, retaining stone, curb stone etc...You just need to replace the mould. The moulds are designed according to your requirement.

Compressed earth blocks machine and operated by the PLC controller. The main electrical appliances all use foreign famous brands such as the Transducer (Japanese Panasonic), Breaker and Contactor (Japanese Fujiand Panasonic), Relay and Industrial computer (Japanese Fuji), Button(Germany Siemens) etc.


DESCRITION OF CONVEYOR BELT:

The conveyor belt has 5 layers and 12 mm thickness so it is very Strong, thus to make sure it has a long life.

DESCRITION OF MOULD

The mold is made of 16 manganese, not the cast steel (No. 45 steel), also not common A3 iron plate as some companies) and will be processed by the heat treatment which will prolong its life (the mold can be used for 150, 000 times) (MOST COMPANIES IN QUANZHOU CAN ONLY USED FOR 100, 000 TIMES)

Guarantee:
We will send you spare parts together with shipment for one year use free of charge started from successful installation date, and during one year if any broken, we will send the intact parts to you for free too.

TECHNOLOGICAL PARAMETERS OF THE PRODUCTION LINE

DESCRITION OF THE PLC
1. Programmable Logic Controller (PLC) is designed with the up-to-date technology with high

Reliability and function, which is one of the mainstays in the world industrial automatic technology.

2. The heart part of this machine is adopted the up-to-date technology from Japanese OMRON. The PLC is a micro-computer and CQMIH type machine is with anti-interference ability and load ability.

3. It is easy to operate and is reliable. The self-diagnostic program helps you to find out the breakdown of the PC system by the indicator (lighting up, blinking and lighting off) on the PC panel.

Some important parts of the PLC:

Touch screen: PANASONIC (JAPAN)

Transducer: PANASONIC (JAPAN)

Contactor: FUJI (JAPAN)

Programmable controller: PANASONIC (JAPAN)

Control switch, indicator light, and starter: PANASONIC(JAPAN)

Breaker: FUJI (JAPAN)

Air switch: LG

Relay: PANASONIC

Press button: SIEMENS (GERMANY)

DESCRITION OF THE HYDRAULIC POWER UNIT:

1. The hydraulic oil needed: Both No. 46 and No. 68 can be used. No. 46 hydraulic oil is mainly used in the area with high temperature while the No. 68 hydraulic oil is mainly used in the area with low temperature. (Note: It is better to use No. 46 hydraulic oil in the Middle East)

2. Some important parts of the hydraulic power unit

Hydraulic Valve: Imported from NORTHMAN, Taiwan and Japan joint venture

3. Advantage

The double oil pump can make sure that the hydraulic power unit can work smoothly even if there are some problems on one oil pump, thus to protect the whole hydraulic power unit.

4. Double Cooling System
We adopt wind and water double cooling system on our hydraulic power unit thus to make sure the temperature of hydraulic oil can be controlled within the required range, if the temperature of hydraulic oil is too high it will then damage the oil pipe and slow down the movement of machine. Please pay attention to the picture of our hydraulic power unit.

Production Capacity of compressed earth blocks machine
Model	Product	Size (mm)	Pcs/Mould	Pcs/Hours
QT6 Machine	Hollow block	390x190x190	6	1440
	Porous brick	240x115x90	15	3600
	Standard brick	240x115x53	30	7200
	Standard brick	240x115x50	32	7680
	Holland block	200x100x60	21	5040
	Paving stone	200x100x60/80/100	24	5760
	Colored Paving brick	225x112.5x D	15	3600
QT8 Machine	Hollow block	390x190x190	8	1920
	Porous brick	240x115x90	18	4320
	Standard brick	240x115x53	39	9360
	Standard brick	240x115x50	42	10080
	Holland block	200x100x60	24	5760
	Paving stone	200x100x60/80/100	32	7680
	Colored Paving brick	225x112.5x D	21	5040
QT10 Machine	Hollow block	390x190x190	10	2400
	Porous brick	240x115x90	27	6480
	Standard brick	240x115x53	59	14160
	Standard brick	240x115x50	69	16560
	Holland block	200x100x60	40	9600
	Paving stone	200x100x60/80/100	44	10560
	Colored paving brick	225x112.5x D	28	6720
Note: Brick size could be customized.The production capacity is affected by material,brick size and other factors. Machine could be customized,we have also YC4 Machine,YC12 Machine,YC1500,YC3000 etc,the relevant data is available upon your request.

We know baking-free brick machine is so popular and its raw materials used on there is a big reason for that.With the development of World economy, the housing construction in our country, building energy efficiency has been the subject of much attention, has been the focus of government and all circles of the society and each construction company.Since baking-free brick machine is developed rapidly used in building materials production, and solve the problem of environmental pollution and resource waste. Multi-function baking-free brick machine, its high recycling rate, reduce production cost, improve the investment benefit. Baking-free brick machine is easy to maintenance, security and stability.All in all, from the point of view of the technical advantage, can make full use of waste resources, greatly reduce the production cost, to create greater profits for every investor.  Our company ,Fujian quanzhou Yongchang machinery.,LTD sell baking-free brick machine, hollow brick machine, cement block machine, brick making machine, block molding machine welcome to inquiry !
