Product Specifications
| Prod Model: |
CS-H60D |
| Markets: |
South America,Southeast Asia,Africa,Mid East,Eastern Asia |
Product Description
1.Application fields
It is used to testing the mass fraction of C, S of steel, alloy, nonferrous metal, cement, ore, catalyst and other materials.
2.Main features
1). Low noise, high sensitivity, high stability of the sensor detects the signal of carbon and sulfur.
2). Intensive designing and MCU control embedding improve the reliability of the instrument.
3). Electronic balance: weighing the sample in variable amount and reading weight automatically.
4). Changing sample amount, expanding scale and application range.
5). Adopting electromagnetic valve to improve the reliability of pneumatic and hydraulic system.
6). Special carbon and sulfur analysis software. The software functions are complete.
a.Based on the WINDOWS analysis software, Chinese menu structure, navigation operation.
b.Screen displays real-time sensor signal and dynamic traces sulfur photoelectric signal. They are intuitive and clear.
c.Curve establishes automatically and it coexists. Single point correction and Multipoint correction coexist. Curves can be optimized operation to use.
d.It has a powerful database functions for real-time observation, query and print.
e.It can network with the front furnace number system to transmit the data automatically.
3.Technical parameter
Analysis method |
Carbon: gas volumetric method |
Sulfur: iodometric method |
Analysis range |
Carbon: ω(C)0.020%-6.000% |
Sulfur: ω(C)0.0020%-0.500% |
Analysis of error |
Carbon meet GB / T223.69-97 standard |
Sulfur meet GB / T223.68-97 standard |
Analysis time |
High speed automatic ignition furnace: 65 seconds,
Tube type furnace: 80 seconds ( two absorption plus 10 seconds ) |
Sample mode |
Electronic balance: weighing the sample in variable amount, weighing range:0- 100g; Reading precision:0.001g |
Reading mode |
Read on computer screen, automatic printing data |
Working environment |
Indoor temperature: 5ºC-40ºC, relative humidity: less than 75% |
Power parameters |
Voltage: AC220V±5%, frequency : 50Hz±2% |
