D6 Bulldozer with Cummins Engine

Name: D6 Bulldozer with Cummins Engine
Brand: China-Manufacturer-Directory.com
SKU: 768810775
Availability: InStock
Rating: 5 (63 reviews)

Supplier:	Xiamen Topway Machinery Co., Ltd.
Price:	US $ 65000/Piece
Min Order:	1UNIT
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	D6
Markets:	South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia
Bulldozer Engine:	Cummins
Bulldozer Operating Weight:	16500kgs
Bulldozer Hydraulic Parts:	High Quality
Walking Mode:	Crawler
Certification:	ISO9001: 2000
Condition:	New
Type:	Bulldozer
Scraper Type:	Bulldozer
Load And Unload Method:	Dozer

Product Description

Hydraulic Bulldozer Main Features:

TM series bulldozer is introduced Japanese Komatsu bulldozer technology featuring high performance capacity, efficiency, safe and reliable in operation
It is semi-rigid suspended, power shift, hydraulically controlled and track-type
Adopted modular design, it is simply to operate, easy to repair and maintenance.
Overflow with difference of pressure, environmental-friendly and energy saving hydraulic system, high working efficiency.
Widely used in building infrastructure and industry including large mining area, port, power plant, road building etc.
Optional equipments (Additional price needed)
Straight tilting blade, Scarifier, Angle blade, Coal pushing blade, U shape blade; Single shank ripper, Three shanks ripper; ROPS, FOPS, Forest defence cabin, A/C, Different track shoes

Specification:

Technical Data\Model		TMD6
Dozer		Tilt
Operating weight with ripper (kg)		16500
Ground pressure (kpa)		55.23
Track gauge (mm)		1880
Min. ground clearance (mm)		445
Gradient		30°/25°
Dozing capacity (m³)		4.5
Blade width (mm)		3297
Max. digging depth(mm)		592
Overall dimentions with ripper(mm)		503732973077
Engine	Type	SHANGCHAI C6121
	Rated revelution (rpm)	1900
	Flywheel power (KW/HP)	119/162
Driving system	Torque converter	Outside separating combination
	Transmission	Planetary, power shifting transmission with three speeds forward and three speeds reverse, speed and direction can be quickly shifted
	Steering clutch	Multiple-disc oil power metallurgy disc compressed by spring. hydraulic operated.
	Brake clutch	Brake is oil two direction floating band brake operated by mechanical foot pedal.
	Final drive	The final drive are double reduction with spur gear and segment sprocket, which are sealed by duo-cone seal, easy to maintanence
Undercarriage system	Type	Swing type of sprayed beam, Suspended structure of equalizer bar
	Number of track rollers (each side)	7
	Pitch (mm)	203
	Width of shoe (mm)	560
	Gear	1st	2nd	3rd
	Forward km/h	0-4.0	0-6.9	0-10.9
	Backward km/h	0-4.8	0-8.4	0-12.9
Implement hydraulic system	Max. system pressure (Mpa)	15.5
	Pump type	Gears pump
	System output (L/min)	178

Product Photos:

Xiamen Topway Machinery Co., Ltd. is a modern enterprise located in Xiamen which is one of the biggest construction manufacture center in China. We are specialized in manufacturing and exporting construction machinery, such as wheel loader, block handling wheel loader, excavator, forklift, backhoe loader, motor grader, bulldozer and telescopic forklift. We always offer our respectable customer high quality products with reliable performance, competitive price and sincere services ensuring every project to be run on schedule.

Topway as a professional one-stop machinery equipment supplier, "QUALITY FIRST" is our philosophy, dedicated to provide reliable products with quicker delivery time, make prompt reaction for spare parts and after sales service, do what we promised, all these has earned a good reputation for us for being a trustworthy partner, and our products are widely accepted by oversea clients from Africa, Middle East, Asia and Latin America countries.

We sincerely hope to work with customers and friends around the world at different cooperation way, we hope to establish win-win co-operation relationship with you.
