Digital AC and DC Clamp Meter (MS2108)

Name: Digital AC and DC Clamp Meter (MS2108)
Brand: China-Manufacturer-Directory.com
SKU: 683300602
Availability: InStock
Rating: 4.6 (61 reviews)

Supplier:	Changzhou Skyvictor Import and Export Co., Ltd.
Price:	Negotiable/Piece
Min Order:	100/Piece
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	MS2108
Markets:	North America,South America,Eastern Europe,Western Europe
Grade:	Professional
LCD Display:	2000 Counts
Diode:	2.7V
Display:	Digital

Product Description

Digital AC/DC Clamp Meter MS2108

Features of Digital AC/DC Clamp Meter:
* Jaw size: Φ 26mm/1.0"
* Test AC/DC voltage and current, resistance, capacitance, frequency and duty cycle
* INRUSH function and true RMS
* Work light and display back light
* Diode check and continuity test
* MAX/MIN and Data hold

Pictures of Digital AC/DC Clamp Meter:

Specifications	Range	Accuracy
DC voltage	660mV/6.6V	±(0.8%+3)
DC voltage	66V/600V	±(1.0%+5)
AC voltage	660mV	±(1.5%+10)
	6.6V/66V	±(1.2%+5)
	600V	±(1.5%+10)
DC current	66A/600A	±(3.0%+10)
AC current	66A/600A	±(3.0%+10)
Inrush current(100ms)	66A/600A	±(10%+60)
Resistance	660Ω/6.6KΩ/66 KΩ/660 KΩ/6.6MΩ	±(1.2%+2)
Resistance	66MΩ	±(2.0%+5)
Capacitance	6.6μF/66μF/660μF/6.6mF/66mF	±(4.0%+3)
Frequency(from clamp)	0~1KHz	±(1.5%+5)
Frequency(from plug)	0~10KHz	±(1.5%+5)
Duty cycle	10%~90%	±3.0%
Features:
Display	Counts	6600
Jaw opening		Φ26mm/1.0"
Auto ranging	Auto & manual	√
Auto power off		√
Inrush	Inrush current measurement: 100ms current integral	√
True RMS	True root mean square measurement	√
Diode	2.7V	√
Continuity buzzer	<50Ω	√
Data hold		√
Low battery display		√
Display backlight		√
Work light		√
General
Power Supply	3x1.5V AAA batteries
Product Size	2087835mm/8.2"x3.1"x1.4"
Product Weight	245g/0.54lb
Safety Rating	CE ETL CAT.III 600V RoHS
