Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
Technical Specifications
Testing: 2.94N (0.3gf)\4.9N(0.5gf)\9.8N (1.0gf)\29.4N (3.0gf )\49N (5.0gf)\98N(10.0)
Exchanging Scales: ( Rockwell, Superficial Rockwell, Brinell)
Min Measuring Unit: 0.062μ M
Magnification of Microscope: 100X( For Observation )200X(For Measurement)
Data Output: Inside Printer and RS-232 Interface
Loading Control: Automatically (load, keep, unload)
Net Weight: 35kg
Max Height of Specimen: 160mm
Power Supply: AC220V± 5%, 50~60Hz
Carried Standard: GB/T4340. (GB/T4340.2 Chinese Standard). JJG151( JJG151 Inspection Rule )
Standard Accessories: Objectives 40x and 10x, Vickers Indenter, Microscope 10x, V Testing Table, Forcipate Testing Table, Power Cable, Standard Hardness Brocks: 2 PCS, etc.
HVS-5 HVS-10 HVS-30 HVS-50 Digital Micro Vickers Hardness Tester adopts large LCD screen to display and menu type structure to choice hardness scales HV or HK, store testing results and data procession automatically, as well as output by printer. By means of interface of RS-232, the instrument can be linked with computer. It can be assembled a device to exchange hardness values among scales.
Usage Range
Heat treated layer, carbonized layer, hardened hard layers, superficial coating, steels, non-ferrous metal, micro and thin shaped components.
Technical Specifications
Data Output: (Inside Printer and 232 Interface
Loading Control: Automatically (load, keep, unload)
Net Weight: 35kg
Max Height of Specimen: 160mm
Max depth of specimen: 135mm
Power Supply: AC220V± 5%, 50~60Hz
Carried Standard: GB/T4340(1.2) Chinese Standard
Standard Accessories: Lens20x. 10x, Vickers indenter, Digital Measuring eyepiece 10x, Large Testing Table, Medium Testing Table and V shaped Testing Table, Power Cable: Lens10x, Vickers indenter, Digital Measuring eyepiece 10x, Large Testing Table, Medium Testing Table and V shaped Testing Table, Power Cable.
|
PROJECT |
HVS-5 |
HVS-10 |
HVS-30 |
HVS-50 |
|
Testing |
2.94N(0.3Kgf)\4.9N(0.5Kgf)\ |
|
9.80N(1Kgf)\19.6N(2.0Kgf)\ |
|
|
|
29.4N(3.0Kgf)\49.0N(5.0Kgf) |
2.94N(0.3Kgf)\4.9N(0.5Kgf)\ |
|
9.80N(1Kgf)\29.4N(3Kgf)\ |
|
|
|
49.0N(5Kgf)\98.0N(10Kgf) |
9.8N(1.0Kgf)\29.4N(3Kgf)\ |
|
|
49.0N(5.0Kgf)\98N(10Kgf)\ 196N(20Kgf)\294N(30Kgf) |
9.8N(1.0Kgf)\49.0N(5.0Kgf)\ |
|
98N(10Kgf)\196N(20Kgf)\ |
|
|
|
294N(30Kgf)\490N(50Kgf) |
|
|
|
Min Measuring Unit |
0.0625μm |
0.0625μm |
0.125μm |
0.125μm |
|
Magnification of Microscope |
100X(For Observation) |
|
|
200X(For Measurement) |
100X(For Observation) |
|
|
100X(For Measurement) |
|
|
