Zhangjiagang Wanhong Machinery Manufacturing Co., Ltd. >> Fold-Bend Machine

Fold-Bend Machine

Name: Fold-Bend Machine
Brand: China-Manufacturer-Directory.com
SKU: 731214165
Availability: InStock
Rating: 4.6 (129 reviews)

Supplier:	Zhangjiagang Wanhong Machinery Manufacturing Co., Ltd.
Price:	US $ 5200/Piece
Min Order:	1/Set
Quantity::
Trade Terms:	FOB,CIF

Product Specifications

Prod Model:	dw38nc
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Max Bending Capacity:	38.1*2.0t
Max Bending Radius:	175mm
Min Bending Radius:	15mm
Max Feeding Length:	2100mm
Max Bending Degree:	190
Control Panel:	PLC*Touch Screen
Rotary Servo Motor Power:	400W (Japan Mitsubishi)
Feeding Servo Motor Power:	1kw (Japan Mitsubishi)
Oil Motor Power:	5kw
Hydraulic Control System:	Japan Yuken
Automation:	Semi-automatic
Type For Fold-bending Machine:	CNC Fold-bend Machine
Application:	Machinery & Hardware
Type:	Pipe and Tube Bending Machine

Product Description

Specifications 1. fold-bend machine(DW-38CNC) 2. Technical: Cold bending 3. Electric: Schneider 4. System: Mistubishi 6. Pipe bending machine

Item	Name	Unit	Data	Remark
1	Max bending capacity	mm	38.1x2.0t
2	Max bending radius	mm	175	Can according to customer requirement
3.	Min bending radius	mm	15
4	Max feeding length	mm	2100	Can according to customer requirement
5	Max bending degree	Degree	190
6	Control Panel		PLC*touch screen
7	Bending unit	piece	16
8	Working speed	bending speed	Deg*sec	45
		Rotary speed	Deg*sec	270
		Feeding speed	mm*sec	900
9	Accuracy	feeding	mm	0.1
		rotary	Degree	0.1
		bending	Degree	0.1
10	Rotary servo motor power	W	400	JapanMitsubishi
11	Feeding servo motor power	Kw	1	JapanMitsubishi
13	The accuracy of roller	mm	Max 70	Can according to customer requirement
14	Oil motor power	Kw	5
15	Max storage units	group	1000	Can enlarge according to requirement
16	Max pressure	MPa	12	Adjustable
17	Hydraulic control system		Magnetic exchange valve	JapanYuken
18	Oil tank	L	190

Our company supplies different kinds of products. High quality and reasonable price. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with good quality at the reasonable price.
