Product Specifications
| Prod Model: |
Y09-3016 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Outside Dim: |
300*360*126 |
| Display: |
LCD |
| Weight: |
0.6kg |
| Battery: |
(Lithium Ion Battery),7.2V,2200mAh |
| Zero Count: |
<10min |
| Flow Rate: |
2.83L/Min |
| Operating Time: |
5 Hours |
| Location Labels: |
0-999 |
| Date Storage: |
1000 Samples (with PC Software) |
| Optional Component: |
External Printer |
| Certification: |
ISO |
| Type: |
Dust Laser Particle Counter |
Product Description
Handheld Air Particle Counter Y09-3016
Handheld Air Particle Counter Y09-301 is the primary choice of measuring instrument by HVAC and indoor air quality experts.
It is the best portable tool for measuring the particles Concentration in the air from filter test and indoor air quality .
Handheld Air Particle Counter Y09-301 can make the measurement more convenient and don't switch interface frequently to get the data due to the powerful data storage and six-channel particle size display.
It can be easy to use in any environment because of light weight . It can be more accurate to access the air quality.
specification
Outside Dim | 300*360*126 mm3(Wide*Deep*High) |
| Display | LCD |
| Weight | 0.6kg |
| Battery | (Lithium Ion Battery),7.2V,2200mAh |
| Power Source | Li-ion charger ,8.4V DC,1A:9-250V AC, 50-60Hz |
| Size Channels | 0.3, 0.5, 1, 3, 5, 10 μm |
| Flow Rate | 2.83L/min |
| Sample Time | 1s-99h |
| Cycles | 0-99 |
| Hold Time | 0-999sec |
| Delay Time | 0-99sec |
| Light source | Laser Diode |
| Zero Court | <=10min |
| Alarm | Low Battery ;100, 1000, 10000 Class /ISO |
| Coincidence Loss | 5%,2000000ps/cf |
| Operating Time | 5 hours |
| output | RS-232 to pc or printer via optional cable |
| Location Labels | 0-999 |
| Data Storage | 1000 Samples (With PC Software) |
| Environmental | 10degrees celsius-40degrees celsius ; Humidity: 20%-90% RH ;Atmosphere Pressure 86Kpa-106Kpa |
| Standard feathure | suitcase ;charger;sampling head;line of communication;communication software ;Automatic Purifier |
| Optional component | External printer
|
Application
？ Cleanroom Monitoring
？ Facility Certification
？ Facility Monitoring
？ Filter Testing
？ Cleanroom Laundries
？ Cleanroom Packing
？ Aerospace
？ Hospital Surgical Rooms
？ Pharmaceutical
？ Paint Spray Booths
？Food Processing Area
？Hard Disk Drive Manufacturing
