| Price: | US $ 300/Piece |
|---|---|
| Trade Terms: | FOB |
| Min Order: | 1/Piece |
| Pay Type: | T/T,Paypal |
| System | |
| Motherboard | Mini-ITX MP-2600N |
| Embedded CPU | Intel Cedar Trail series CPU ATOM N2600 |
| Memory | Soldered onboard 2GB DDR3-1333 SDRAM |
| Chipset | Intel NM10 Express Chipset |
| ATA |
1×Serial ATA II ports with 3GB/s HDD/SDD transfer rate 2×Serial ATA III ports with 6GB/s HDD/SDD transfer rate |
| LAN Chipset | 1×realtek RTL8111DL Gigabit Ethernet controllers |
| Audio | ALC 662 2-channel Audio Codec integrated |
| Mult I/O | |
| Serial Port |
4×DB-9 Male connector Port Support 4×RS232 ports (COM4 is RS232/422/485 selectable) |
| USB Port | 5×USB 2.0 ports |
| Video Port |
1×HDMI Port connector 1×DB-15 female connector Port for Analog RGB 1×LVDS connector,supports dual channels 24-bit LVDS output 1×LVDS connector,supports single channels 18-bit LVDS output |
| Selectable Port | 1×DB-25 female connector Digital I/O Port LPT |
| PS2 Port | 1×6-pin Mini-DIN for Keyboard and Mouse |
| Expansion Bus |
1×PCI slot w/ riser card 1×Mini PCI-E slot w/ riser card |
| Environmental | |
| Operating Temp | -10~60 |
| Storage Temp | -40~85 |
| Relative Humidity | 20~85% |
| Vibration | 3 Grms/5~450Hz/random operation |
| Shock & Crash |
Operating 20G(11ms),Non-operating 320G with HDD Operating 80G(11ms),Non-operating 32G with SSD |
| Qualification | |
| Certification | CCC , CB, CE,FCC,ROHS |
| Power Requirement | |
| Power Input | DC 12V Input (BNC DC Input) |
| Power Consumption | 40W(Max.) |
| Power Adapter | 60W AC/DC Adapter |
| Storage | |
| Type | 1×2.5 "Drive bay for STAT II HDD-320G/SSD-32G |
| Mechanical | |
| Construction | Aluminum |
| Mounting | Wall-mount (Default integrated)/Din rail mounting |
| Weight/Gross weight | 1.5kg/2.0kg |
|
Dimensions (W×D×H) |
180×58×195mm |
| Prod Model: | mini-fanless pc |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Motherboard: | Mini-Itx MP-2600n |
| Embedded CPU: | Intel Cedar Trail Series CPU Atom N2600 |
| Chipset: | Intel Nm10 Express Chipset |
| Memory Capacity: | 2GB |
| CPU: | Intel |
| HDD Capacity: | 320GB |
| GPU: | AMD |
