ISO Quality Professional Slag Dryer/Slag Drying Machine with Large Capacity

Name: ISO Quality Professional Slag Dryer/Slag Drying Machine with Large Capacity
Brand: china-manufacturer-directory.com
SKU: 699168282
Availability: InStock
Rating: 5 (38 reviews)

Price:	US $ 4000-80000/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Set
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

ISO quality professional slag dryer/slag drying machine with large capacity

slag dryer special characteristics:

1.This new type slag dryer is new environmental protection product, saving energy and reducing loss of fuel
3.our special design slag dryer, investment, small footprint, and supporting civil
works less
4.with many years experience in the field of drying,our slag dryer with reliable,
simple operation, convenient maintenance, safe,durable and other Superiority,
have a very good market.
5.Special design of the internal structure of slag dryer,with special drying and
moisture control, material output moisture minimum up to 5% or less, meet the
material widely.
6. Temperature of slag dryer can be adjust in drying process to ensure the quality
of slag not change.
7.Continuous work and large capacity.

The slag dryer applications include:
This new type slag dryer also can used to drying other material,such as lignite,
kaolin, dry municipal sludge, paper sludge, leather sludge, printing and dyeing
sludge, chemical materials and pharmaceutical liquid fermentation residue,
food fermentation, sugar residue, chemical organic waste, and more.

Main technical parameters of slag dryer machine:

Model	Diameter (m)	Length (m)	speed (r/min)	Installation obliquity (%)	Drying temperature (°c)	Capacity (t/h)	Motor (kw)	Weight (ton)
Φ0.8x8	0.8	8	3-6	3-5%	≥800	0.6-0.8	3	3.5
Φ1.0x10	1.0	10	3-6	3-5%	≥800	1-1.5	4	7
Φ1.0x12	1.0	12	3-6	3-5%	≥800	1.5-1.8	4	8
Φ1.0x15	1.0	15	3-6	3-5%	≥800	1.5-2	5.5	10
Φ1.2x10	1.2	10	3-6	3-5%	≥800	1.8-2	7.5	14
Φ1.2x12	1.2	12	3-6	3-5%	≥800	2-3	11	15
Φ1.2x15	1.2	15	3-6	3-5%	≥800	2.5-3	11	18
Φ1.5x15	1.5	15	3-6	3-5%	≥800	3-3.5	15	20
Φ1.5x18	1.5	18	3-6	3-5%	≥800	3.5-4	15	23.5
Φ1.5x20	1.5	20	3-6	3-5%	≥800	4.0-4.5	15	25
Φ1.8x15	1.8	15	3-6	3-5%	≥800	4.5-5.0	18,5	28
Φ1.8x18	1.8	18	3-6	3-5%	≥800	5.0-5.5	18.5	30
Φ1.8x20	1.8	20	3-6	3-5%	≥800	5.5	18.5	33
Φ2.0x15	2.0	15	3-6	3-5%	≥800	5.5-6	18.5	35
Φ2.0x18	2.0	18	3-6	3-5%	≥800	6-6.5	18.5	42
Φ2.0x20	2.0	20	3-6	3-5%	≥800	6.5-6.8	18.5	50
Φ2.2x20	2.2	20	3-6	3-5%	≥800	6.5-7.0	22	56
Φ2.2x22	2.2	22	3-6	3-5%	≥800	7.0-7.5	22	58
Φ2.4x20	2.4	20	3-6	3-5%	≥800	7.5-8	30	60
Φ2.5x20	2.5	20	3-5	3-5%	≥800	8-9	30	63
Φ2.5x25	2.5	25	3-5	3-5%	≥800	10-11	37	68
Φ2.6x20	2.6	20	3-5	3-5%	≥800	9-10	37	65
Φ2.6x25	2.6	25	3-5	3-5%	≥800	11-12	37	73
Φ2.6x30	2.6	30	3-5	3-5%	≥800	15-18	45	80
Φ2.8x20	2.8	20	3-5	3-5%	≥800	13-15	45	75
Φ2.8x22	2.8	22	3-5	3-5%	≥800	15-16	45	78
Φ2.8x30	2.8	30	3-5	3-5%	≥800	18-20	55	83
Φ3.0x20	3.0	20	3-5	3-5%	≥800	18-20	55	78
Φ3.0x22	3.0	22	3-5	3-5%	≥800	20-25	55	80
Φ3.0x30	3.0	30	3-5	3-5%	≥800	25-28	75	90

Prod Model:	SKW
Markets:	South America,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Material:	Q235B Carbon Steel Plate or as Client Requirement
Installation:	Supplier Dispatch Engineer
Voltage:	380 V Others
Power(W):	5.5-110 Kw
Dimension(LWH):	Different Model Different
Weight:	6- 300 Ton
Certification:	CE, ISO9001:2000
Warranty:	Two Years
Application:	Construction,Metallurgical,Mining Industry etc
Drying Temperature:	200-1000 Degree
Structure:	Rotary Type Drier
Operational Method:	Continuous
Operation Pressure:	Atmospheric Dryer
Movement Way:	Fixed
Heating Mode:	Hot Air
