Product Specifications
| Prod Model: |
FEBC-3121-S001 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
IPC |
| CPU Card Size: |
Full-size Card |
| Hard Disk Rack Type: |
Board Type |
| Installation: |
Wall-Mounted |
| Application: |
Industrial |
| Accessories: |
Industrial Power Supply |
| CPU Type: |
Intel Atom |
| System Expansion Slot: |
Mini Pcie |
Product Description
Features:
Ultra-slim, fanless
Intel Atom D2550 1.86GHz
Intel®NM10
1xDDRIII SODIMM, Max. 4GB
1x Mini Card support mSATA
VGA&HDMI display
2x1000Mbps Ethernet /4COM/8bit DIO
5 USB(one buil-in) /CFAST
Shock & Vibration resistance
SYSTEM | CPU | Intel® Atom D2550 Processor 1.86GHz dual core processor |
| MEMORY | DDRIIISODIMM,up to 4 GB |
| EXPANSION | MINI CARDx1,support mSATA |
| DISPLAY | VGA&HDMI |
| M/K | USB |
| Ethernet | Intel 82583V 10/100/1000Mbps RJ-45 ×2 |
| SSD | CFAST,mSATA,SATADOM |
| HDD | 2.5" HDD Bay or 3.5" HDD Bay |
| SERIAL PORTS | RS-232/422/485×2,RS-232×2 |
| USB | USB 2.0 × 5 |
| CONTROL | power on/off × 1 |
| LED LIGHT | power light×1,HDD light×1 |
| WATCH DOG TIMER | timer system reset/interrupt |
| POWER | DC IN-PUT
VOLTAGE IN-PUT | built-in DC-DC convertor |
| DC12V |
AC IN-PUT
VOLTAGE IN-PUT | external adapter(for option) |
| 100VAC~240VAC@50~60Hz |
| OS | Windows 7,Windows XP,Windows XP Embedded,Linux |
| OPTION | WIFI / 3G |
| MECHANICAL | STRUCTURE | aluminum case,Wrinkle shape for cooling, ultra-slim |
| COLOUR | gray |
| INSTALLATION | in-wall, desktop |
| DIMENSIONS | 228.7*163*49mm |
| WEIGHT | 1.85Kg |
| ENVIROMNTAL | OPERATION TEMPERATURE |
20~70ºC-SSD Without Airflow
-10~50ºC-HDD Without Airflow |
STORAGE TEMPERATURE | -20°C~ 70°C (-4°F ~ 158°F) |
| STORAGE HUMIDITY | 5~90%@40°C, non-condensing |
| VIBRATION | 5 grms / 5 ~ 500Hz / in work status(CFD) |
| 1 grms / 5 ~ 500Hz /in work status ( built -in HDD module) |
| SHOCK | 50 g peak acceleration (duration 11ms)(CFD) |
| 20 g peak acceleration( duration 11ms)( built -in HDD module) |
| EMC | CE /FCC A class ,UL |
| ORDER INFORMATION |
| FEBC-3121/S001 |
| Embedded PC ,Intel Atom D2550 1.86GHz2*LAN,/4COM (2*RS232/422/485 Option ),VGA/HDMI,MiniPCIe with SIM card slot ,/5xUSB/Cfast/3.5'HDD Bay |
| FEBC-3121/S002 |
| Fanless,Atom D2550,2x1000Mbpas Ethernet /4 COM/5 USB/ 8bit DIO/CFAST/ 3.5" HDD Bay |
| PA-60DC12 |
| AC/DC power adapter,DC12V/5A 60W |
| WBESITE |
| WWW.JHCTECH.COM.CN/EN |
