Product Specifications
| Prod Model: |
WH-A7 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Resolution Ration: |
8 Dots/Mm(384 Dots/Line) |
| Printing Speed: |
30mm/Sec |
| Printing Method: |
Direct Thermal Line Printing |
| Usage: |
Receipt Printer |
| Style: |
Black and White |
| Interface Type: |
RS232/Ttl,Parallel |
| Type: |
Thermal |
| Max. Paper Size: |
57mm*30mm |
Product Description
Stylish, delicate and elegant appearance
Very silent printing thru direct thermal printing method
High speed and low power consumption option
Support 3.3V low voltage system
Serial(RS-232C, TTL) interface/Parallel interface
Function setting, prompting for self-motion print
Abundant figure/curves/characters print function
Easier paper loading
Item:Specification
Printing method:Direct thermal line printing
Paper loading way easy paper loading
Paper width:57 mm
Print width:48 mm
Resolution ration:8 dots/mm(384 dots/line)
Life of printing head:6× 106 character lines
Printing speed:30mm/sec (when the utilization rate is 25%. )
Character size:6x8dots, 8x16dots, or12x24dots
Chinese character library:GB2312, 16x16dots, or24x24dots
Outline dimension(WxHxD mm) :110.5mmx64mmx66mm
Installation dimension(WxH mm):103mmx57mm
Inlaid deepness:58mm
Paper supplied:Thermal roll paper (57mm wide, 35mmø )
Interface Serial(RS-232C, TTL)/Parallel interface
Input Power:DC3.5V-9V, DC 15W/5V, 3A, MAX 4A
Operating temperature:5° C ~ 50° C
Storage temperature:-20° C ~ 60° C
Operating humidity:10° C ~ 80° C
Storage humidity:10° C ~ 90° C
