Product Specifications
| Prod Model: |
WH-A9 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Usage: |
Receipt Printer |
| Style: |
Black and White |
| Interface Type: |
RS232/Ttl,Parallel |
| Type: |
Thermal |
| Max. Paper Size: |
57mm*50mm |
Product Description
Very silent printing thru direct thermal printing method
High speed (50mm/sec, based on character ratio 25%)
High speed and low power consumption option
Support 3.3V low voltage system
Support 3.5V-9V power (best performance when 7.2-8.5V)
Serial(RS-232C, TTL) interface/Parallel interface
Abundant figure/curves/characters print function
Easier paper loading
Item Specification
Printing method: Direct thermal line printing
Paper out detection: Paper end sensors function
Paper loading way Easy paper loading
Paper width: 57 mm
Print width: 48 mm
Resolution ration: 8 dots/mm(384 dots/line)
Life of printing head: 6× 106 character lines
Printing speed: 50mm/sec (when the character ratio is 25%)
Character: 6x8dots, 8x16dots, or12x24dots
Chinese character library: GB2312, 16x16dots, or24x24dots
Outline dimension(WxHxD mm) 84mmx98mmx57mm
Installation dimension(WxH mm): 78mmx92mm
Inlaid deepness: 54mm
Paper supplied: Thermal roll paper (57mm wide, 50mmø )
Interface Serial(RS-232C, TTL)/Parallel interface
Input Power: DC 3.5V-9V, 15W/ DC 5V, 3A
Operating temperature: 5° C ~ 50° C
Storage temperature: -20° C ~ 60° C
Operating humidity 10° C ~ 80° C
Storage humidity10° C ~ 90° C
