Product Specifications
| Prod Model: |
WH-E23 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Usage: |
Receipt Printer |
| Style: |
Black and White |
| Interface Type: |
Serial RS232 |
| Type: |
Thermal |
| Max. Paper Size: |
57mm*20mm |
Product Description
Very silent printing thru direct thermal printing method
Paper end sensors function and self-motion memory printing function
With high speed 40mm/sec(when the utilization rate is 25%. )
Abundant figure/curves/characters print function
Add coordinate curve printing function
Easier paper loading (key ejecting type)
Item:Specification
Printing method:Direct thermal line printing
Paper out detection:paper end sensors function
Paper loading way easy paper loading
Paper width:57 mm
Print width:48 mm
Resolution ration:8 dots/mm(384 dots/line)
Life of printing head:6, 000, 000 character lines
Printing speed:50mm/sec(when the utilization rate is 25%. )
Character per line
Character size:12x24dots
Chinese character library:GB2312 24x24dots
Outline dimension(WxHxD mm):82mmx47.5mmx34.7mm
Installation dimension(WxH mm):78+0.5mm(W)x43.5+0.5mm(H)
Inlaid deepness:32.2mm
Paper supplied:Thermal roll paper (57mm wide, 20mmø )
Interface Serial:RS-232
Input Power:DC 5V, 3A
Operating temperature:5° C ~ 50° C
Storage temperature:-20° C ~ 60° C
Operating humidity :10° C ~ 80° C
Storage humidity:10° C ~ 90° C
