Wuxi Poshstar Industry Co., Ltd. >> Plastic (Cap Handle Ring) Injection Molding Machine (PS-350-1900M)

Plastic (Cap Handle Ring) Injection Molding Machine (PS-350-1900M)

Name: Plastic (Cap Handle Ring) Injection Molding Machine (PS-350-1900M)
Brand: China-Manufacturer-Directory.com
SKU: 749230395
Availability: InStock
Rating: 4.4 (84 reviews)

Supplier:	Wuxi Poshstar Industry Co., Ltd.
Price:	US $ 30000-35000/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	PS-350-1900M
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type:	Preform Injection
Automation:	Automatic
Structure:	Horizontal
Computerized:	Computerized
Plastic Type:	Thermosetting
Plasticizing Way:	Plunger Type
Certification:	ISO9001:2008

Product Description

Guarantee : 1 year.

Installation:
We can send technician to install the machine or customer can send technician to our factory for training.
Buyer need to pay air thicket & food & hotels.

Remark:
(a) All specifications and designs are subject to change without notice.
(b) The price of the machine all are in US dollars based on FOB Shanghai.
(c) The price is base on 380V, 50Hz, 3 Phase, for special power, add additional 5% of all machine.

				PS-350/1900M
ITEMS				A		B		C
		Screw Diameter	mm	60		65		70
INECTION UNIT		Screw L/D Ratio	L/D	21.7		20		18.6
		Shot Size(Theoretical)	cm3	845		992		1151
	(Ps)	Injection Weight	g	769		903		1047
		Injection Pressure	MPa	235.3		200.5		172.9
		Injection Rate into Air	cm3/s	216.7	259.1	254.3	304.1	294.9	352.7
		Injection Stroke	mm	299
		Injection Speed	mm/s	77/92
	(ACC)	Injection Speed(ACC)	mm/s	303
		Screw Speed	rpm	158/189
		Clamping Force	KN	3500
CLAMPING UNIT		Clamping Stroke	mm	690
		Space Between Tie Bar	mm	680*680
		Max. Mold Height	mm	700
		Min. Mold Height	mm	280
		Eject Stroke	mm	160
		Eject Force	KN	67
		No. Of Ejector Pins	piece	13
		Max. Pump Pressure	MPa	17.5
OTHERS		Pump Motor Power	KW	31/37
		Heater Power	KW	30.6
		Hopper Capacity	L	50
		Oil Tank Capacity	L	750
		Weight	t	12

WUXI POSHSTAR INDUSTRY Co., Ltd. is established in 2003, succeeding blow moulding techniques & experiences accumulated many years by our engineers and technicians in this field.

We have been able to carve a niche in the industry due to the unstinting support of our industrious team; In other words, our team is the backbone of our organization. Our professionals possess vast experience, expertise and extensive knowledge in their respective domain which allows them to utilize their skill and talent wisely. We also can provide all the necessary facilities to our workforce in order make the latest and most advanced technology available to them. We have appointed the following professionals as a part of our team:

(1)Designers

(2)Quality Analysts

(3)Skilled Craftsmen

(4)Machine Operators

(5)Packaging Experts

(6)Sales and Marketing Professionals

Looking forward to cooperating with you in future.

Contact Person: Peter

Tel: 0086-510-82820051

Mobile: 0086-13812175742

Fax: 0086-510-82822112

Add: Times International C, Nanchang Area, Wuxi city, Jiangsu province, China.
