Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Mesh Count: |
3mesh to 100mesh |
| Wire Diameter: |
0.10mm to 0.80mm |
| Hole Shape: |
Square |
| Application: |
Living Organisms Because Non-Toxic |
| Material: |
Titanium Wire |
Product Description
Titanium mesh is lightweight and about 60% of the specific gravity of stainless steel wire mesh, thermal expansion coefficient is about 50% of the stainless steel wire cloth. In addition, about half of the stainless steel mesh and has a initialized modulus is also flexible nature.
Characteristics: Chemical resistance is a summary of the nitric acid - strong acid system, and withstand seawater, also wet chlorine gas. For high-strength, corrosion resistance without deterioration due to cold, stress corrosion, has a feature almost no pitting.
Titanium wire mesh is used for living organisms because non-toxic, it can be used such as artificial bone, will also be in direct, fit into the body. And other chemical equipment, oil refining equipment, industrial equipment, etc. It can also be used for pulp and paper.
Weave Pattern: Plain weave and twill weave.
Packing: Waterproof paper with plastic cloth, then put into wooden box.
|
Specification List of Titanium Wire Mesh |
|
Mesh/Inch |
Wire Dia mm d |
Mesh Opening mm w |
Opening Area A % |
Mesh /Inch |
Wire Dia mm d |
Mesh Opening mm w |
Opening Area A % |
|
3 |
0.800 |
7.670 |
82.0% |
20 |
0.300 |
0.970 |
58.30% |
|
4 |
1.000 |
5.350 |
71.0% |
20 |
0.350 |
0.920 |
52.5% |
|
4 |
0.890 |
5.460 |
74.0% |
24 |
0.250 |
0.808 |
57.9% |
|
5 |
1.000 |
4.080 |
64.5% |
30 |
0.280 |
0.567 |
45.0% |
|
6 |
0.800 |
3.433 |
65.8% |
32 |
0.250 |
0.544 |
46.5% |
|
8 |
0.810 |
2.365 |
55.40% |
35 |
0.230 |
0.496 |
46.9% |
|
9 |
0.800 |
2.022 |
51.3% |
40 |
0.250 |
0.385 |
36.0% |
|
10 |
1.000 |
1.540 |
36.8% |
40 |
0.210 |
0.425 |
44.8% |
|
10 |
0.635 |
1.905 |
56.2% |
50 |
0.180 |
0.328 |
41.7% |
|
12 |
0.600 |
1.517 |
51.3% |
60 |
0.150 |
0.273 |
41.7% |
|
14 |
0.406 |
1.408 |
60.2% |
80 |
0.120 |
0.198 |
38.7% |
|
16 |
0.450 |
1.138 |
51.3% |
80 |
0.100 |
0.218 |
46.9% |
|
18 |
0.254 |
1.157 |
67.2% |
100 |
0.100 |
0.154 |
36.8% |
