Xiamen Topway Machinery Co., Ltd. >> TM165-3 Heavy Bulldozer with Shangchai Engine for Sales

TM165-3 Heavy Bulldozer with Shangchai Engine for Sales

Name: TM165-3 Heavy Bulldozer with Shangchai Engine for Sales
Brand: china-manufacturer-directory.com
SKU: 706042072
Availability: InStock
Rating: 4.6 (136 reviews)

Supplier:	Xiamen Topway Machinery Co., Ltd.
Price:	US $ 65000/Piece
Min Order:	1UNIT
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	TM165-3
Markets:	South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia
Bulldozer Engine:	Cummins
Bulldozer Operating Weight:	17750kgs
Bulldozer Hydraulic Parts:	High Quality
Walking Mode:	Crawler
Certification:	ISO9001: 2000
Condition:	New
Type:	Bulldozer
Scraper Type:	Bulldozer
Load And Unload Method:	Dozer

Product Description

Hydraulic Bulldozer Main Features:

TM series bulldozer is introduced Japanese Komatsu bulldozer technology featuring high performance capacity, efficiency, safe and reliable in operation
It is semi-rigid suspended, power shift, hydraulically controlled and track-type
Adopted modular design, it is simply to operate, easy to repair and maintenance.
Overflow with difference of pressure, environmental-friendly and energy saving hydraulic system, high working efficiency.
Widely used in building infrastructure and industry including large mining area, port, power plant, road building etc.
Optional equipments (Additional price needed)
Straight tilting blade, Scarifier, Angle blade, Coal pushing blade, U shape blade; Single shank ripper, Three shanks ripper; ROPS, FOPS, Forest defence cabin, A/C, Different track shoes

Specification:

Technical Data\Model		TM165-3
Dozer		Tilt
Operating weight with ripper (kg)		17750
Ground pressure (kpa)		68.3
Track gauge (mm)		1880
Min. ground clearance (mm)		353
Gradient		30°/25°
Dozing capacity (m³)		4.6
Blade width (mm)		3442
Max. digging depth(mm)		420
Overall dimentions with ripper(mm)		544734423160
Engine	Type	WEICHAI WD10G178E25
	Rated revelution (rpm)	1850
	Flywheel power (KW/HP)	121/165
Driving system	Torque converter	3-element 1-stage 1-phase
	Transmission	Planetary, power shifting transmission with three speeds forward and three speeds reverse, speed and direction can be quickly shifted
	Steering clutch	Multiple-disc oil power metallurgy disc compressed by spring. hydraulic operated.
	Brake clutch	Brake is oil two direction floating band brake operated by mechanical foot pedal.
	Final drive	The final drive are double reduction with spur gear and segment sprocket, which are sealed by duo-cone seal, easy to maintanence
Undercarriage system	Type	Swing type of sprayed beam, Suspended structure of equalizer bar
	Number of track rollers (each side)	6
	Pitch (mm)	203
	Width of shoe (mm)	500
	Gear	1st	2nd	3rd
	Forward km/h	0-3.32	0-6.26	0-11.40
	Backward km/h	0-4	0-7.57	0-13.87
Implement hydraulic system	Max. system pressure (Mpa)	12
	Pump type	Two groups Gears pump
	System output (L/min)	185
