Tengzhou Sanzhong Machinery Manufacture Co., Ltd. >> Vertical and Horizontal Milling Machine (X6332WA)

Vertical and Horizontal Milling Machine (X6332WA)

Name: Vertical and Horizontal Milling Machine (X6332WA)
Brand: China-Manufacturer-Directory.com
SKU: 666546365
Availability: InStock
Rating: 4.8 (63 reviews)

Supplier:	Tengzhou Sanzhong Machinery Manufacture Co., Ltd.
Price:	US $ 1-10000
Min Order:	1
Quantity::
Trade Terms:	By Sea

Product Specifications

Prod Model:	X6332WA
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Color:	Ral-Color
Type:	Metal Cutting Machine

Product Description

X6332WA vertical and horizontal milling machine

1. Table swivel 45 degree.
2. Auto feed on two axes, motorized on Z aixs
3. Three-axis hardened

Specification	X6332WA
Max. horizontal milling dia. (mm)	100
Spindle taper (mm)	ISO40
Max. vertical milliing dia. (mm)	Φ25
Distance between spindle and table (mm)	100--500
Spindle speed range r.p.m	80---5440(vertical) 40-1300(12)(Horizontal)
Spindle travel (mm)	127
Table size (mm)	1250x320
Table travel (mm)	600x340x400
Motor (kw)	2.2(v) 3(h)
N.W/G.W (kg)	1550/1700
Package size mm	1520x1630x2200
Other requirements	400v,50Hz, 3 Phase

Our company is special in producing milling machine, radial arm milling machine and multi-function turret milling machine which are popular in Europe, Southeast Asia market. With high quality, good credit, concentrate all for customer. We are obey the principle to satisfy with our customer by actively innovating, absorb other companies' advantage, perfecting every product, moves customers with good credit, wins customers with high quality. We will perfect our service with higher, faster, newer, stricter woking attitude, and afford our efforts for your success.
