Product Specifications
| Prod Model: |
VT02 FLUKE, VT04A FLUKE, VT04 FLUKE |
Product Description
Hongkong and Shanghai Total Co., Ltd. Is specialized in exporting Measurement & Meter, anemometer, dew point meter, dewpoint meter, portable dewpoint meter, humidity meter, humidity tester, psychrometer, digital psychrometer, insulation tester, lux meter, light meter, moisture meter, moisture tester, wood moisture meter, digital moisture meter, grain moisture tester, soil moisture meter, thickness gauge, coating thickness gauge, ultrasonic thickness gauge, metal thickness gauge, paint thickness gauge, thickness meter, thickness tester, ultrasonic thickness tester, paint thickness meter, coating thickness meter, sound level meter, digital sound level meter, stroboscope, digital stroboscope, tachometer, digital tachometer, temperature meter, thermometer, thermometer, infrared thermometer, digital thermometer, temperature meter, temperature data logger, temperature data recorder, ultrasonic distance meter, range finder, vibration meter, capacitance meter, metal detector, voltage detector, tire pressure gauge, digital tire pressure gauge, leab hardness tester, megohmmeter, surface resistance tester, calibrator, process calibrator, gas detector, halogen leak detector, EMF meter, electronic scale, electronic weighing scale, pocket scale, glossiness meter, shore hardness tester, phase rotation tester, laser liner, tree huger, battery tester, water tester/equipment, gloss meter, window tint meter, laser diameter tester, PH meter, TDS meter, ec meter, ORP meter, conductivity meter, conductivity tester, PH controller, ORP controller, PH monitor, ORP monitor, dissolved oxygen meter, PH electrode, ORP electrode, industrial pH electrode, industrial ORP electrode, refractometer, abbe refractometer, gem refratometer, magnetic stirrer, water hardness tester, polarimeter, fiber microscope. Laser level, automatic level, cross line laser, spectrophotometer. Multimeter, analog multimeter, digital multimeter, clamp meter, digital clamp meter, ac dc clamp meter, AC DC power clamp meter, digital AC clamp meter, digital special multimeter.
Key Features
|
VT02
|
VT04/VT04A
|
Built-in digital camera
|
Yes
|
Thermal heat map overlay
|
Yes, five blending modes
|
Image optics systems
|
PyroBlend® optic
|
PyroBlend® Plus optic
4x sharper image than VT02
|
Field of view
|
20° x 20°
|
28° x 28°
|
High/Low temperature alarms
|
_
|
Yes
|
Time lapse image capture
|
_
|
Yes
|
Auto-monitor alarm
|
_
|
Yes
|
Battery type
|
Four (4) AA batteries
|
VT04: Li-ion rechargeable
|
VT04A: Four (4) AA batteries
|
Ergonomics
|
Slim pocket-sized design
|
Weight
|
385 g (13.5 oz)
|
VT04: 350 g (12.5 oz)
|
VT04A: 384 g (13.5 oz)
|
Hot and cold markers
|
Yes
|
General Specifications
|
Battery Life
|
Eight (8) hours
|
Temperature measurement range
|
-10 °C to +250 °C (14 °F to 482 °F)
|
Temperature measurement accuracy
|
± 2 °C or ± 2%
|
Temperature measurement
|
Yes, center point
|
Storage medium (micro SD card)
|
Stores up to 9,999 images on four (4) GB micro-SD card)
|
Infrared spectral band
|
6.5 µm to 14µm
|
Level and span
|
Auto
|
Focus mechanism
|
Focus free
|
Alignment of blended visual image and infrared heat map
|
NEAR: < 23 cm (9 in) from target
FAR: > 23 cm (9 in) from target
|
Dimensions
|
21 cm x 7.5 cm x 5.5cm (8.3 in x 3 in x 2.2 in)
|
File format
|
.is2 format saved to SD card
|
.bmp* or .is2 format saved to SD card
|
Software
|
With .is2 format, user can create professional reports or export images in SmartView® software (BMP, DIB, GIF, JPE, JFIF, JPEG, JPG, PNG, TIF, and TIFF
|
Features to extend
battery life
|
_
|
Adjustable screen brightness, auto screen dimming after 2 minutes, configurable auto-off time*
|
Persistent settings
|
Background temperature and Near/Far mode revert to factory settings
|
Previous settings are retained so you can start work as soon as your VT04 or VT04A turns on*
|
Factory reset option
|
_
|
Easily return to default settings; does not affect date and time*
|
Carrying case
|
Soft case for portability
|
VT04: Hard case
|
VT04A: Soft case for portability
|
Safety and compliance
|
CFR47: 2009 Class A. Part 15 subpart B
CE: EN 61326:2006
IEC/EN 61010-1:2010
|
Warranty
|
Two (2) years
|
