Product Specifications
| Prod Model: |
DLQC-FDJ004 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
1580*880*1780mm |
| Style: |
Tsi Electronical Controlled Engine Training Set |
| Brand: |
Dolang |
| Model: |
Dlqc-Fdj004 |
| Type: |
Teaching Model |
| Laser Model: |
Tsi Electronical Controlled Engine Training Set |
| Usage: |
Car Educational Model |
Product Description
Note: (Optional models available to customers aaToyota Corolla 1.8L, Toyota Hiace, Volkswagen Santana 2000, Volkswagen Santana
Volkswagen TSI Electronical Controlled Engine Training Set DLQC-FDJ004
Introduction
The training set adopt Volkswagen Sagitar TSI direct injection engine assembly, with complete accessories, can be used to complete various training Content of engine load. All components adopt original parts, QC strictly testified, in accordance with Production Quality Management standard of ISO9001: 2008, suit for car engine structure and maintenance practical training in the medium and senior vocational schools and car training institutions, satisfy the requirement of teaching training project on the electronic controlled engine structure, working principle, fault diagnosis, fault setting and exclusion assessment.
Basic Configuration
TSI engine assembly, engine control unit, engine circuit plug, combination instrument, training panel, diagnostic block, tank assembly, up and down pipe, Kettle, thermostat switch, cooling fan assembly and bracket, pressure gauge, vacuum gauge, ignition switch, battery, starter, generator, fuel pump assembly, fuel filter, air filter, Ignition key with a chip, anti-theft control unit, anti-theft Identification coil, intake and exhaust manifolds, catalytic assembly, oil tank, movable bench and mobile casters, general power switch, relay and fuse box, instruction manual and user training guide etc.
Features
1. Demonstrate the engine work, run smoothly, actually refelect the EFI gasoline engine structure and working principle
2. Demonstrate engine oil pressure, vacuum pressure, oil pressure normal operating pressure
3. Equipped with digit display meter to display the related sensor working static value and dynamic value.
4. Training sets are equipped with electronic engine control system schematics and detection terminal, through a variety of professional instruments to detect the signal parameters of sensors, actuators etc. Such as voltage, resistance, frequency etc.
5. Equipped with diagnostic blocks can be connected to a dedicated or general-auto decoders, to complete reading fault codes of engine electronic control system, clearing fault codes, reading data stream, matching adjustment, programming, testing, testing terminal components etc engine diagnostic function.
6. Fault setting and assessment system (please refer to the detailed function introduction of fault setting and assessment)
7. Rotate position of training sets are equipped with safety shields to keep safe.
8. Training sets equip with gasoline extinguisher and short circuit self-protection device
9. With locking casters for mobile devices, easy to move for teaching
Training Content
1. Engine sctructure and composition training
2. Engine component setup position training
3. Engine sensor voltage, resistence, signal testing training
4. Engine fuel pressure, Vacuum pressure, oil pressure training
5. Engine Schematics analysis trainging
6. Engine control unit fault code reading, fault code eliminate, data flow reading, Anti-theft matching adjustment, programming, terminal component testing training
7. Engine troubleshooting and confirm training
8. Engine fault setting and exclusion training
9. Engine practical operation and theoretical exam training
Technique Features
1. Support frame adopt imported panit special for car, high temperature coating, with anti-corrosion function
2. Support frame material is welded with quality square tube(40*60*3mm)
3. Size: 1580× 880× 1780mm
Factory:
Dolang Technology Equipment Co., Ltd. was founded in 1998.
Dolang is a company specialized in didactic training equipment for technical schools,
training schools, engineer schools, engineer training centers and manufacture of high-
tech enterprises.
Dolang take up 9240 sq. m. Have more than 40 professional engineers and more than
100 skilled workers.
Our products are involved in various education equipment industry fields.
We serve 80 universities and more than 300 vocational colleges.
With self-operation export & import license, our products have being exported to German,Canada, France, Russia,Brazil,Colombia, Peru, Mongolia, Tunisia, Mexico,
Indonesia, Iraq,Cyprus, Vietnam, Kazakhstan etc.
We will do our best all the time to be the trend setter in didactic field!
Our factory located in Pioneering park overseas Chinese Scholars Jinan city, Shandong Province .
We have very strong technical teams with more than 40 engineers and experienced workers. Our products have exported for more than 7 years.
Product range:
1) Electrical technology Know-how Training Set
2) Innovative E-skills &Technology Training Series
3) MCU Technology Training Series
4) Machine Tools Electrical Control Training Series
5) Machine Tools Electrical Control Training Series(Model-type)
6) CNC Machine Tools Maintainance Training Series(Model-type)
7) Building Automatic Training Series
8) PC Training Series
9) Innovative industrial Automatic Control Technology Training Series
10) Pneumatic Training Series
11) Hydraulic Training Series
12) Sensor Training Series
13) Motor Training Series
14) Mechatronic Training Series
15) MPS Training Series
16) FMS Training Series
17) Mechanical Training Series
18) Automobile Education Training Series
19)Engraving Training Series
Packaging and Delivery Details:
Packaging Detail:
? Packaging for training kit: plastic package + carton + plywood pallets
? Packaging for training equipment: plastic package + plywood pallet
Delivery Detail: 20 to 50 days after Received advanced payment.
After-sale Service And Training for Foreign User
? For our exported equipments, the Warranty is one year, within one year, if there is any problem for spare parts(except damage by man-made) We can supply and replace free of charge. And if after one year, we also supply the service. The difference is user need to pay it.
? We dispatch our professional and experienced engineer to install equipments and make training for the end users
Certificate
Question
Q1:What factors affect the price?
A. The quality of components: All the components we use are real industrial components which under EURO standard.
B. Technique: we pay much attention on the technique and details. Our products meet the requirement of Germany standard
C. Quantity: The price is up to the quantity of each item.
Q2: All equipments are designed by Dolang?
A. Yes. All our equipments are designed by ourselves.
B. The design department including: Electric research design department, Electrical research design department, Mechanical research and design department, Software research design department, Pilot test department and technical documents department.
Q3: Does Dolang have after sale service and training service?
A. After sale service: All our products have one year maintenance from the date of pick up except artificial damage.
B. Training: Customer may ask our engineer to training them in their company or come to Dolang for training
Shandong Dolang Technology Equipment Co., Ltd. Was founded as a partner of Shandong university in 1998. Thanks for the customers, professional engineers and all our skilled workers, Dolang has been grown up to a professional and powerful global enterprise with 16 years dedicated experience on the didactic equipment. As a member of Worlddidac Association, our products are made under the requirement of ISO9001, ISO24001 and OHSMS28001.
We are professional on manufacturer electrical & electronic, PLC, fluid mechanical, hydraulic, pneumatic, process control, mechatronics, automation, CIM training and automobile training systems.
Besides the physical training system, Dolang provide solutions for customer such as system thinking, E-learning and so on.
Our products are involved in various education equipment industry fields. We serve in 100 universities and more than 300 vocational colleges in China. With self-operation export & import license, our products have being exported to France, Russia, Mongolia, Tunisia, Mexico, Brazil, Peru, Indonesia, Iraq, Cyprus, Vietnam, Kazakhstan etc.
