Product Specifications
| Prod Model: |
TZ02D,TZ03D,TZ04D,TZ06D,TZ08D,TZ10D,TZ12D,TZ16D |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Condition: |
New |
| Moving Type: |
Wheel Loader |
| Rated Load: |
200-1600kg |
| Certification: |
CE |
| Matching Power: |
20-180HP |
| Driving System: |
Hydraulic |
| Colour: |
Red, Black, Customized |
| Connect Person: |
Emma 18766152072 |
Product Description
Wheel tractor front end loader/ manure forks match front end loader
Main features:
1. Models cover from TZ02D to TZ16D. Matching Tractors models from 20hp to 180hp.
2. Structural design is in accordance with ISO standard, can match with most models of domestic and foreign tractors.
3. More than 10 kinds of attachments are for choices. Have the versatility and interchangeability for tractors in ISO standard.
4. High Strength Low Allow Structural Steels and High Strength Abrasion Resistant Steels are adopted in production, Structural Strength and Durability are achieved.
5. The hydraulic control system uses Europe imported components, products' dirigibility and reliability are enhanced.
Our company:
1. A holding company of Shandong Academy of Agricultural Machinary Sciences.
It was established on the basis of Academy's Technology Centre and Trail Production
Factory in 2001.
2. Main products of our company including: Front end loader, Backhoe, Snow removing machineries ( like Snow blade, Snow sweeper, Snow blower etc), Forestry machineries
( like Log trailer with crane, Log splitter, Wood chipper etc), Front linkage and PTO,
Grass mower, Dozer blade and Compost turner etc.
Reasons for choosing SAMTRA Products:
I. Strong Technical Support:
1. More than 80 professional and technical personnels;
2. Top universities and institutes cooperator;
3. A subordinate to Shandong Agricultural Machinery Research Institute
II. Top Quality Assurance:
1. Strict control and selection of materials;
2. Completely self manufactured and installed;
3. Advanced equipments and first-class production technology;
4. Sound management system and solid economic strength
III. Advanced Testing Measures:
1. Exclusive R&D, testing center;
2. Capable of undertaking national research projects;
3. Exclusive professional platform
|
Model |
|
TZ03D |
TZ04D |
TZ05D |
TZ06D |
|
Matching Tractor |
kw(hp) |
14.7~22.1(20~30) |
22.1~29.4(30~40) |
29.4~36.8(40~50) |
36.8~44.1(50~60) |
|
Rated Lift Capacity |
kg |
300 |
400 |
500 |
600 |
|
Max. Dump Height |
mm |
1800 |
2000 |
2100 |
2200 |
|
Digging Depth |
mm |
100 |
120 |
140 |
140 |
|
Bucket Capacity |
m3 |
0.18 |
0.3 |
0.35 |
0.4 |
|
Dump Angle |
(° ) |
42~45 |
42~45 |
42~45 |
42~45 |
|
Weight |
kg |
470~650 |
500~680 |
530~720 |
660~800 |
|
Main Specifications of Front End Loader |
|
Model |
|
TZ08D |
TZ10D |
TZ12D |
TZ16D |
|
Matching Tractor |
kw(hp) |
44.1~58.8(60~80) |
58.8~66.2(80~90) |
88.2~102.9(120~140) |
140-180 |
|
Rated Lift Capacity |
kg |
800 |
1000 |
1200 |
1600 |
|
Max. Dump Height |
mm |
2350 |
2350 |
2500 |
2500 |
|
Digging Depth |
mm |
180 |
180 |
200 |
200 |
|
Bucket Capacity |
m3 |
0.48 |
0.6 |
1 |
1 |
|
Dump Angle |
(° ) |
42~45 |
42~45 |
42~45 |
42~45 |
|
Weight |
kg |
680~830 |
800~980 |
960~1150 |
960~1150 |
Shandong Sunco Agricultural Equipment Technology Co., Ltd. is a state-owned holding company, which is subordinate to Shandong Academy of Agricultural Machinery Sciences. It was merged by Academy's Technology Centre and Trial Production Factory in 2001, and was formally registered in 2009.
The Academy's Technology Centre and Trial Production Factory were respectively established in 1959 and 1964. Over the past 50 years, they were mainly engaged in R&D and trial-manufacture of tractors, farm machineries, agricultural transportation vehicles, field operating machineries, harvesting machineries etc. Moreover, they obtained more than 500 scientific and technological achievements, among which, over 80 were awarded with national, provincial or ministerial science and technology award.
As the reform and development needs of China's market economic system and research institutions, after the merging of Academy's Technology Centre and Trial Production Factory, the research direction focus has shifted from tractors to tractors and tractor equipments, the focus of work shifted from research to industrial development and production operations. After more than 10 years of development, Shandong Sunco Agricultural Equipment Technology Co. Ltd has embarked on a rapid developing road of corporate operation.
At present, our company covers an area of over 140000 square meters, has more than 140 employees, including more than 50 professional and technical personnels. Among which, there are 6 national researchers, more than 10 senior engineers, and more than 20 engineers. In 2012, we were awarded the title of National High-tech Enterprise.
Main products of our company including: Front End Loader, Backhoe Excavator, Snow Removing Machineries (like Snow Blade, Snow Sweeper, Snow Blower etc), Forestry Machineries (like Log Loading Trailer with Crane, Log Splitter, Wood Chipper etc), Front Linkage and PTO, Grass Slasher, Dozer Blade and Compost Turner etc.
Main Tractors we matching with including: Large and medium-sized domestic tractor manufacturers e. G. Lovol (Foton), YTO, Cherry, Jinma, SF, Wuzheng (TS), Enfly DQ, Dongfeng, LZ, SJH etc. And other famous international tractor brands like John Deere, New Holland, Kubota, Mahindra, Massey Ferguson, Belarus Minsk, Deutz etc. Products are mainly exported to the developed countries in Europe, Australia, America and Asia etc, with annual exports over 5000 sets.
