X4+Y4 Heavy Duty Machine Trolley

Name: X4+Y4 Heavy Duty Machine Trolley
Brand: China-Manufacturer-Directory.com
SKU: 766570915
Availability: InStock
Rating: 4.8 (150 reviews)

Supplier:	Ningbo Grandlifting Co., Ltd.
Price:	US $ 39/Piece
Min Order:	200/Piece
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	X4+Y4,
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Capacity:	8-36t
Material:	Steel
Usage:	Tools
Wheel Type:	Solid Wheel
Wheel Amount:	8
Style:	Unfolding
Surface Handling:	Paint
Certification:	TUV
Lift Drive:	Hand
Load Capacity:	8-36t

Product Description

Cargo Trolley X+Y Series

1. Capacity of cargo trolleys: 8-36T
2. Rollers of cargo trolleys: 8pcs/12pcs/16pcs
3. Color: Yellow, red orange & etc

8ton to 64ton Hand Cargo Transportation Trolley X+Y Series

- XY series trolley is combined by X series trolley and Y series trolley.
- X series trolley has the advantage of automatic adjustment of balance. It has stable working on rugged site.
- Y series trolley has the advantage of adjustable range, it can be adjusted according to the size of cargos.
- The rollers of these two series are made of special quality material. They have the advantage of anti-abrasion and anti-pressure. The working place won't be damaged easily.

Item No.	Model		Capacity Per set (t)	Touching Face Size(mm)	Handle Length Adjustable Scope(mm)	Shape Size(mm)	Height (mm)	Capacity(single) (T)	A	B	C	D	E
ZHMT-1	X4+Y4	X4	8	φ150	800	230x230	110	4	1000	223	230	130	170
ZHMT-2	X4+Y4	Y4	8	130x130	300-1000	170x140	110	4	1000	223	230	130	170
ZHMT-3	X8+Y8	X8	16	φ160	1100	560x420	110	8	1130	556	500	200	200
ZHMT-4	X8+Y8	Y8	16	200x160	400-1300	220x200	110	8	1130	556	500	200	200
ZHMT-5	X12+Y12	X12	24	φ180	1100	750x450	110	12	1130	730	550	256	200
ZHMT-6	X12+Y12	Y12	24	220x180	400-1400	256x200	110	12	1130	730	550	256	200
ZHMT-7	X18+Y18	X18	36	φ200	1500	750x500	110	18	1430	755	630	256	300
ZHMT-8	X18+Y18	Y18	36	280x180	400-1500	300x250	110	18	1430	755	630	256	300
