Black Solder Mask Double-Sided Bottom Contact FPC Connector Flexible PCB

Name: Black Solder Mask Double-Sided Bottom Contact FPC Connector Flexible PCB
Brand: China-Manufacturer-Directory.com
SKU: 768211745
Availability: InStock
Rating: 4.9 (74 reviews)

Supplier:	Shenzhen Fortunemount Technology Co., Ltd.
Price:	Negotiable/Piece
Min Order:	200/Piece
Quantity::
Trade Terms:	FOB

Product Specifications

Prod Model:	FPCB-3
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Copper Foil:	ED/Ra
Max. Board Size:	800X400mm
Min. Board Thickness:	0.1mm
Soldering Thermal Resistance:	300deg/10 Seconds
Performance Test:	100% Electrical and Electricity Performance Test
Structure:	Double-Sided FPC
Material:	Polyimide
Combination Mode:	Adhesive Flexible Plate
Application:	Aviation and Aerospace
Conductive Adhesive:	Anisotropic Conductive Adhesive
Brand:	Cayera

Product Description

Application

Products are applied to a wide range of High-tech industries such as: LED, telecommunication, computer application, lighting, game machine, industrial control, power, automobile and high-end consumer electronics, ect.

Advantage of Flexible PCB Boards

Flexible PCB design and layout
Flexible, space savings
Reduced wiring errors
Increase the flexibility of connection compared with mechanical connectors
Easier installation and service
Higher circuit density
More robust operating temperature range
Stronger signal quality
Improve manufacturing yield and reliability
Improve reliability and impedance control
Reduce size and weight
Improve aesthetics of finished products

Specification:

Types:	Single-sided, Double-sided, Multi-layers (max 6 layers) and Rigid-flexible PCB, Aluminium board
Surface Finishing:	HASL(LF), Gold plating, Electroless nickel immersion gold, Immersion Tin, OSP(Entek)
Base Material:	Polyimide(Kapton), Polyester(PET), Aluminium, FR4
Copper Foil:	ED/RA
Min. Line Width:	2 mil
Min. Line Spacing:	2 mil
Min. Hole Size:	0.2mm
Max. Board Size:	800x400mm
Min. Board Thickness:	0.1mm
Min. Solder Mask Thickness:	10um
Solder Mask Types:	Green, yellow, black, white, blue, red and clear
Profiling:	Punching, Routing, V-cut
Soldering Thermal Resistance:	300°C/10 seconds
Peeling Strength:	≥1.4kg/cm
Surface Resistance:	105mΩ
Insulation Resistance:	105mΩ
Dielectric Strength:	9.8x105v/cm
Flammability:	UL-94V-0
Performance Test:	100% electrical and electricity performance test
