CNC Machine Cxk0632A Lathe Machine Tool
Product Specifications
| Prod Model: |
CXK0632A |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| The Maximum Turning Diameter Of Bed: |
230mm |
| The Largest Diameter Rotary Pallet: |
80mm |
| Max Processing Length: |
Collect 200mm/ Chuck 120mm |
| Spindle Head Form: |
A2-5 |
| Spindle Bore Diameter: |
40mm |
| Trombone Through-Hole Diameter: |
32mm |
| X-Axis Stroke: |
260mm |
| Z-Axis Stroke: |
240mm |
| X Rapid Traverse: |
5m/Min |
| Z Rapid Traverse: |
8m/Min |
| Type: |
Horizontal Lathe |
| Processing Accessory: |
Chuck CNC Lathe |
| Tool Holder: |
Single-tool Holder CNC Lathe |
| Power Source: |
Hydraulic Pressure |
| Controlling Mode: |
CNC |
| Automatic Grade: |
Automatic |
| Setting Mode: |
Floor-type |
| Precision: |
High Precision |
Product Description
internal threading machine CXK0632A cnc lathe mill drill tap machine and multifunction lathe from haishu
The main technical parameters
Item |
Unite |
Technical data |
The maximum turning diameter of bed |
mm |
Φ230 |
The largest diameter rotary pallet |
mm |
Φ80 |
Max processing length |
mm |
collect 200/ chuck 120 |
Spindle head form |
|
A2-5 |
Spindle bore diameter |
mm |
Φ40 |
Trombone through-hole diameter |
mm |
Φ32 |
Tapping the largest size |
|
M12 |
X / Z axis repeat positioning accuracy |
mm |
0.012/0.013 |
X-axis stroke |
mm |
260 |
Z-axis stroke |
mm |
240 |
X rapid traverse |
m/min |
5 |
Z rapid traverse |
m/min |
8 |
Spindle drive form |
|
servo |
C axis function |
|
360° Arbitrary indexing |
Spindle speed range |
r/min |
0-3000 Forward and reverse
|
Spindle motor power |
kw |
3 |
Turret form |
|
In line turret / electric turret optional |
Milling power head power |
W |
Standard 200, >200(Special Order) |
Milling speed |
rpm |
1000~10000 |
Chuck Type |
|
ER08 (Optional) |
The maximum diameter of the tool holder |
mm |
Standard φ5, >φ5(Special Order) |
Number of milling power head
|
|
Optional
|
Y-axis |
|
Optional |
Overall dimensions
((L×W×H)) |
mm |
1600×1000×1550 |
Machine weight |
kg |
1000 |
GUARANTEE AND AFTER-SALE SERVICES:
1.one year guarantee for whole machine except of CNC system, which guarantee is three years
2.24-hours technical support by E-mail or telephone
3.User-friendly English software or Russian or Spanish, Users manuals and Detailed Videos/CD
4.Provide extra accessories for the machine
5.Also provide service of make program according to your drawings
6.Customized or special design is welcome.
Taian Haishu Machinery Co., Ltd. is a professional production mechatronic product, collection development, manufacture, sales of high-tech enterprises. Company under the two divisions: One is the CNC machine tools division, the leading product is the "haishu" brand of CNC lathes and machining centers; One is the test equipment division, the leading product is "Taishanhaite" brand common rail test bench and injectoin pump, fuel injector test bench. Founded in March 2001, covers an area of 15000m2, building area of 8000m2, fixed assets 16 million yuan(RMB), has passedISO9001: 2008 international quality management system certification and European CE certification. The company has strong technical force, with a group of young and promising in the machine and test rig design and manufacture, electrical design and application of CNC technology and software development expertise and skills. Advanced 2D and 3D CAD, document management to achieve the PDM. Product innovation, Equipment CNC, Management information, Which has become the industry technology leader.
The company has a Ministry of Internal Trade and the Ministry of Foreign Trade, with independent import and export rights. The products are sold to more than 20 domestic provinces, cities and autonomous regions, and exported to 30 countries including: USA, Britain, Germany, Italy, Turkey, Greece, Sweden, Bulgaria, Romania, Denmark, Czechoslovakia, Lebanon, New Zealand, Australia, Peru, Ecuador, Colombia, Chile, Russia, Belarus, Lithuania, Bahrain, Korea, India, Indonesia, Malaysia, Iran, Thailand, Philippines, Mongolia.
Main products: 1. Horizontal flat bed CNC lathe, 2. Horizontal slant bed CNC lathe, 3. Vertical CNC lathe, 4. CNC turning center, 5. CNC pipe thread lathe, 6. CNC milling machine, 7. CNC machining center, 8. CNC grinding machine.
Characteristic services: Bear machining overall program design and implementation. Include: Site planning, equipment layout, tooling tool provide, processing program design, remote operation monitoring. Machine shop to achieve unmanned.
The company has many years of experience in development and manufacturing of CNC machine tools, "technology innovation, integrity service" as a business philosophy, with new and old customers at home and abroad in close cooperation and common development.
