Product Specifications
| Prod Model: |
1000LX3 |
| Markets: |
North America,Eastern Europe,Southeast Asia,Oceania,Eastern Asia,Western Europe |
| 1000X3: |
40MPa |
| Finished Dosage Form: |
Liquid |
| Certification: |
SGS |
| Type: |
Extraction Equipment |
Product Description
1. Extractor
This device is equipped with jacket water recycle heating system. Temperature adjustable.
Building Material: S. Steel 304
Volume : 1000L ×3 units)
Max. working pressure: 40MPa
2. Separator
It is also equipped with with jacket water recycle heating system. Temperature adjustable.
Building Material: S. Steel 304
Separator 1:
Volume : 350L 1 unit
Max. working pressure: 20MPa
Separator 2:
Volume : 350L 1 unit
Max. working pressure: 12MPa
3.CO2 high pressure pump
Flow: Max. 6000L/h frequency convertible
Max. working pressure: 40MPa pump head with cooling system
4. Co-solvent pump
Flow(double plunger) 50L/h mechanical adjustable
Max. working pressure: 40MPa
5. Chiller
Refrigeration 580Kw/h Air cooling or water cooling
Temperature control range: 0ºC~+5ºC meet the technical requirement
6. Purifying system
Building Material: S. Steel 304
Max. working pressure: 2000L 16MPa
7. CO2 Storage tank
Building Material: 1Cr18Ni9Ti
Volume: 20m3 21.7 bar
Max. working pressure: 10MPa
8. Temperature control system
Control range: from room temp.~75ºC adjustable(water base)
Dynamic control accuracy: ±1ºC double digital displaying screen
9. Safety guard device
1. Electric contact pressure gauges are installed at the outlet of plunger pump. Working pressure can be set and the pump will stop automatically in case the pressure is exceeding the set pressure.
2. Extractor, separators, distillation column are equipped with safety valves according to its Max working pressure. It will release pressure automatically in case the pressure is exceeding the set pressure.
10. Condenser
Building Material: S. Steel 304
CO2 Mid-storage tank: 4000L/98 bar 1 unit
11. Hoisting system
With electric hoister for loading and discharging. 10 meters 2T Power: 3Kw 1 unit
12. Platform:
Material: Carbon or S. Steel. I Unit
13. Pipe line
Valves and fittings
All the parts in contact with raw material are made from S.steel 1Cr18Ni9Ti. All the valve rod and valves are hardened. It is durable.
14. Trolley
Material: S. Steel. 2 Units
15. Others
1.Power supply: 3 phases 4 line 380V/50HZ Total power: 58KW,normal production: 36KW
2.CO2:Food grad ≥99.5%. User provide it himself
