Model | CNC-CG4000 | CNC-CG5000 | CNC-CG6000 | CNC-CG7000 | CNC-CG8000 |
Track Span(L) (mm) |
4000 | 5000 | 6000 | 7000 | 8000 |
Cutting Width (L-800mm) (mm) |
3200 | 4200 | 5200 | 6200 | 7200 |
Overall Width (L+800mm) (mm) |
4800 | 5800 | 6800 | 7800 | 8800 |
Longitudinal Track Length (mm) |
14000 (could be extended) | ||||
Valid Cutting Length (mm) |
12000 (could be extended) | ||||
Driving Way | Single Drive | Double Drive | |||
Traverse Speed (mm/min) |
50-4000 | 50-6000 | |||
CNC Torch |
Standard: 2 groups (the torch amount is on clients’ decision) |
||||
Power | 50Hz 220V | ||||
Cutting Thickness (mm) |
Flame: 6-100 (could up to 400 if use large flowage) |
||||
Cutting Model | Flame/Plasma |
Markets: | South America,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
---|---|
Function: | Flame, Plasma |
