PAL Multiple Frequency Signal Generator (ZBL6898B)

Name: PAL Multiple Frequency Signal Generator (ZBL6898B)
Brand: China-Manufacturer-Directory.com
SKU: 676397192
Availability: InStock
Rating: 4.5 (49 reviews)

Supplier:	Zhejiang BC & TV Technology Co., Ltd.
Price:	Negotiable/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB

Product Specifications

Prod Model:	ZBL 6898B
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type:	CATV（Cable Television）Equipment

Product Description

Features
1 Power ON/OFF controlled by computer
2 Each output and total output controlled by computer
3 Modulation Degree ON/OFF controlled by computer
4 Working Status Protection
5 Remote Control

RF Parameters
Item	Units	Value
Working Frequency	MHz	48-862
Frequency Accuracy	kHz	± 10
Frequency Total Deviation	kHz	± 50
Out-of-band Rejection	d B c	≥ 80
Max Output Level	d B m V	≥ 95
Single Output Attenuation	d B	≥ 10
Step	d B	≤ 0.1
Total Output Attenuation	d B	40
Step	d B	1
Output Impedance	W	75
Modulation Degree		≥ 99.4 %( TURN ON)
Phase Noise	dBc/Hz	≤ -85 ( 10kHz)
Phase Noise	dBc/Hz	≤ -100( 100kHz)
Modulation Signal Parameters
Inner Line Frequency	Hz	15625
Frequency Accuracy	Hz	± 2
External Line Frequency Input: TTL Level
Other Parameters
Working Voltage:	AC	220V ± 10%
		50Hz ± 5%
Apparent Power	VA	520
Packing Information
a. Weight:	kg	155
b. Dimension ( mm):	(W)x(D)x(H)	595x550x1400
Environment
Working Temperature	º C	10~30
Relative Humidity	RH	( 20-75) %
Limited Temperature	º C	0~40
Storage Temperature	º C	-40~60

Zhejiang BC&TV Technology Co., Ltd. is a leading manufacturer specialized in providing digital TV headend, optical equipment, CATV network equipment, digital/analog TV meters, and Ethernet equipment for clients from all over the world.
Our company was founded by 7 companies and was chosen as the reform demonstration base authorized by Zhejiang Provincial Government.

We boast a regular staff of 120 members, among whom more than 80 graduated from university with one senior engineer, 15 senior engineers and 40 medium-grade professional title holders.

We offer optical transmitter, optical receiver, optical platform, optical workstation, EDFA, FTTH Node, CATV amplifier, agile QAM modulator, DS3 adopter, TS multiplexer, digital matrix switcher, digital/analog TV meter, 98/84chs PAL channel signal generator, and 110chs NTSC signal generator media converter.
