Product Specifications
| Prod Model: |
LREC6210PF |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| LAN Card Chipset: |
Broadcom 5708 Network Card |
| Product Series: |
Gigabit LAN Card |
| Connector: |
Sc Connnector LAN Card |
| Performance: |
Best Compatible All Operate System LAN Card |
| Warranty: |
3 Years Warranty LAN Card |
| Network Card Service: |
OEM&ODM LAN Card |
| Type: |
Wired |
| Interface: |
PCI Express |
| Transmission Rate: |
10/100/1000Mbps |
| Application: |
Desktop |
Product Description
Overview
The LR-LINK LREC6210PF network card is a high performance PCI Express multifunction network adapter for either standard or low profile slots running over a fiber-optic network environment.
In addition to delivering Gigabit Ethernet networking, the LREC6210PF LAN card supports TOE (TCP/IP Offload Engine) for Windows only, Internet Small Computer System Interface (iSCSI).
The Network Card Advantages:
Use the server chipset, can support more fuctions
Compatible all the OS
PCB 4 layer, 1.5oz, 4mil, more stable, longer using time, smaller resistance
Two line power: 3.3V/1.2V
DC-DC power supply, avoid the card effecting by power influence
All use the good quality materials
Support PXE
Use the TI power controller, the best controller manufacturers in the world, it can provide a stable working enviroment
The LAN Card Standard Features:
Performance Gigabit Ethernet Throughput
Up to 1000Mbps Ethernet transfer rate delivers outstanding network performance that improves response time and removes bottlenecks across the entire network.
Accelerated iSCSI
Accelerated iSCSI allows the LREC6210PF to multi-function as both as a network adapter and as a storage host bus adapter, thereby providing access to storage platforms and to servers over a single connection. Additionally, the LREC6210PF offloads the iSCSI software to the hardware for improved performance.
Load Balancing
Transmit Load Balancing (TLB) and Switch-Assisted Load Balancing (SLB) are two advanced features used to build a bigger pipe for improved networking bandwidth. These port bonding techniques enable users to use up to eight adapter ports in a ProLiant server and aggregate their throughput up to a theoretical maximum of 16 Gigabits per second full-duplex transmission.
Checksum and Segmentation Offloads, and Interrupt Coalescing
When running as a standard Gigabit adapter, the LREC6210PF network card features TCP Checksum Offloads as well as TCP Segmentation Offloads and Interrupt Coalescence. These features reduce the load on the CPU for overall improved system response. Interrupt Coalescence is a feature that groups multiple packets and issues a single interrupt to the host. This process improves host efficiency.
Scalability and Reliability
Network Fault Tolerance, sometimes called "failover" or "NIC redundancy, " allows for the installation of multiple LREC9710PF server adapters or other network adapters so that the active device can be backed up by a redundant adapter to improve availability. The HP teaming utility also allows users to specify that when a failed adapter is fixed and replaced, the original adapter resumes its function as the primary network connection.
Management Support
LREC6210PF supports SNMP.
Configuration Utilities
Enable initial diagnostics within Windows, Linux, and DOS operating systems. Configure network adapter teaming in a Windows environment. The Windows adapter teaming configuration utility includes a patented teaming GUI for Microsoft Windows 2000 and 2003 operating systems. Support for scripted installations of teams in a Microsoft Windows environment allow for unattended OS installations.
Technical Specifications
Compliance
IEEE 802.3z, 802.3X, Dynamic 802.3ad, 802.3p, 802.1Q
PCI Express ver 1.0A
General Specifications
Main chip: Broadcom 5708S
On-board memory: 92KB
Data rate: 1000 Mbps, Half- and full-duplex
Data path: Four lane (X1) PCI Express compatible with X1, X4, X8, and X16 PCI Express slots
Interrupt levels: INTA
Connector: SC Port
Operating system support Standard Gigabit Ethernet:
DOS NDIS2
Netware(ODI16)
Windows XP 32-bit(64-bit)
Windows Server 2003 32-bit(64-bit)
Windows Vista 32-bit(64-bit)
Windows 7 32-bit(64-bit)
Windows 8 32-bit(64-bit)
Windows 8.1 32-bit(64-bit)
Windows Server 2008 32-bit(64-bit)
Windows Server 2008 R2 32-bit(64-bit)
Windows Server 2012
Windows Server 2012 R2
Linux
Sun Solaris
VMware ESX/ESXi 4.1/5.0/5.1/5.5
