Price: | US $ 7.62/Piece |
---|---|
Trade Terms: | FOB |
Min Order: | 50/Piece |
Pay Type: | L/C,T/T,Paypal,Western Union |
Prod Model: | S-75W |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Output Type: | Single |
Output Power: | 1 - 50W |
Input Voltage: | Full Range |
Voltage Regulating Mode: | Frequency Modulation Type |
Connection Mode: | Series Switching Power Supply |
Starting Mode: | Self-excited Switching Power Supply |
Warranty: | 2 Years |
Power Supplying System: | Terminal Power Distribution Equipment |
Certification: | CB |
Brand: | Hongyin |
75W Single Output Switching Power Supply S-75 series
Features:
Low price and high reliability
105ºC output capacitor
AC input power suitable for the world
High efficiency and low operation temperature
Soft-start current can reduce the AC input impact effectively
With short -circuit and overload protection
Compact size, light weight
100% full-load burning test
Installed with EMI filter, minimum wave
SPECIFICATIONS | ||||
OUTPUT | ||||
Model | S-75-12 | S-75-15 | S-75-18 | S-75-24 |
DC Voltage | 12V | 15V | 18V | 24V |
Rated Current | 6.3A | 5.0A | 4.2A | 3.1A |
Current Range | 0-6.3A | 0-5.0A | 0-4.2A | 0-3.1A |
Rated Power | 74W | 74.1W | 74.2W | 74W |
Ripple & Noise | 120mVp-p | 150mVp-p | 150mVp-p | 150mVp-p |
Voltage Adj. Range | ±10% | ±10% | ±10% | ±10% |
Voltage Tolerance | ±1% | ±1% | ±1% | ±1% |
Inlet stability | ±0.5% | ±0.5% | ±0.5% | ±0.5% |
Load stability | ±0.5% | ±0.5% | ±0.5% | ±0.5% |
Setup, Rise, Hold Up Time | 800s,50ms,10ms/115VAC 300ms,50ms,80ms/230VAC at full load | |||
|
| |||
INPUT |
| |||
Voltage Range | 88~132VAC/176~264VAC selected by switch 47~63Hz; 248~370VDC | |||
AC Current | 2.2A/115V 1.1A/230V | |||
Efficiency | 75% | 75% | 77% | 79% |
Inrush Current | Cold-start current 30A/115V 60A/230V | |||
Leakage Current | <1mA/240VAC | |||
|
| |||
PROTECTION |
| |||
Over Load | 105%~150% | |||
Protection type: plusing hiccup shutdown Reset:auto recovery | ||||
|
| |||
ENVIRONMENT |
| |||
Working Temp., Humidity | -10ºC~+60ºC(Refer to output derating curve), 20%~90%RH | |||
Storage Temp., Humidity | -20ºC~+85ºC, 10%~95%RH | |||
Temp. Coefficient | ±0.03%/ºC(0~50ºC) | |||
Vibration | 10~500Hz,2G 10min,/1cycle,Period for 60min,Each axes | |||
|
| |||
SAFETY |
| |||
Withstand Voltage | I/P-O/P: 3KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC | |||
Isolation Resistance | I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC | |||
|
| |||
STANDARD |
| |||
Safety Standard | UL1012TUV EN60950(IEC950,UL1950)Approved | |||
EMC Standard | CLSPR22(EN55022),IEC801-2,3,4,IEC555-2 Verification | |||
|
| |||
OTHERS |
| |||
Dimension | 159*97*38mm(L*W*H) | |||
Weight | 0.56Kg |
