1. Stylish and elegant appearance
2. Support printing dot map of different density and loaded map.
3. Paper end sensors and paper nearly end sensors function
4. Add two cashbox driver signals
5. Printer head overheat protect function
6. Abundant figure/curves/characters/barcode print function
7. Easy to use and simple to maintain
8. Easier paper loading
Item Specification
Printing method Direct thermal line printing
Cashbox Two Cashbox driver signals
Paper out detection paper end sensors and paper nearly end sensors function
Paper loading way easy paper loading
Paper width 57 mm
Print width 48 mm
Resolution ration 8 dots/mm(384 dots/line)
Life of printing head 6× 106 character lines
Printing speed 20lps
Character 6x8dots, 12x24dots
Chinese character library GBK, 24x24dots
Outline dimension(WxHxD mm) 116mmx184.5mmx92mm
Paper supplied Thermal roll paper (57mm wide, 60mmø )
Interface USB interface Serial(RS-232C, TTL)/Parallel interface
Input Power DC 12V-24V, 25W
Operating temperature 5° C ~ 50° C
Storage temperature -20° C ~ 60° C
Operating humidity 10° C ~ 80° C
Storage humidity 10° C ~ 90° C
Beijing Bright Technology Development Co., Ltd is a leading manufacturer of mini printers for over 16 years. The Company is a high technology firm which was established in 1998, and specializes in research, design, manufacture and sales of mini printers and interrelated products. Now we have many professional direct selling service network in Beijing, Shanghai, Hangzhou, Shenzhen, Guangzhou and other big cities in China.
