Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
Main Features:
Features Description:
High accuracy measuring: Linearity: Better than 0.5%, Repeatability: Better than 0.2%, Accuracy: Better than ± 1%
Non-intrusive measuring: Non-intrusive, clamp-on transducer, no pressure drop, no pipe disturbance
Wide measuring range: Several types transducer for selection, measuring pipe size: From DN15mm to DN6000mm
Chinese & English menu: Chinese & English display, easy to operate
Large capacity battery: Built-in rechargeable Ni-MH rechargeable battery, provide over 20 hours of continuous operation
Built-in printer: Built-in mini thermal printer with instant and timing print of over 20 measuring data
Built-in data logger: Uplink over 20 measuring data to computer or internet
General Specification:
Items: Specifications
Main unit: 2 line x 20 character LCD with backlight
Working temperature: -20--60
Mini thermal printer with 24 line character output
4 x 4 + 2 pushbutton keypad
RS-232 interface for networking
Transducer options:
TS-1: Small size transducer (magnetic) for pipe size: DN15-100mm, liquid temperature ≤ 110
TM-1: Medium size transducer (magnetic) for pipe size: DN50-1000mm, liquid temperature ≤ 110
TL-1: Large size transducer (magnetic) for pipe size: DN300-6000mm, liquid temperature ≤ 110
Liquid types: : Water, sea water, industrial sewage, acid and alkali liquid, various oils etc. Liquid which can transmit sound wave
Flow velocity range: 0-± 30m/s
Accuracy: Better than ± 1%
Power Supply: Built-in rechargeable Ni-MH battery (for 20 hours operation) or AC 220V
Power Consumption: 2W
Charging: Intelligent charging with AC 220V
Weight: Net weight: 2.5kg (main unit)
Remarks: With a high strength carrying case suitable for normal and harsh environment.
