Product Specifications
| Prod Model: |
Dk-Ndct/RJ45 5-12L |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model Number: |
Dk-Ndct/RJ45 5-12L |
| Usage: |
Signal Surge Suppresion |
| Nominal Discharging Current: |
5ka(8/20us) |
| Maximum Discharging Current: |
10ka(8/10us) |
| Ports: |
12 |
| Material: |
Aluminum Alloy and Polycarbonate |
| Feature: |
Easily Assembled |
| Light Color: |
White |
Product Description
DK-nDCt/RJ45 5-12L Network Signal Surge Protector
Powerful network signal surge protection device, 12 lines protection, more practical, more useful
This network signal surge protection device is suitable for the surge protection of floor switching equipment signal and network signal of computer room. It is also for other equipments of 10/100M network.
Features
(1)Standard RJ45 interface
(2)Multi-level protection, low residual voltage,
Product installation and application:
(1)This product is installed between the signal channel and the protected devices, the output is connected with the protected equipment;
(2)Applies to the lightning Protection of 100M Ethernet and local area network
|
Product Name |
DK-nDCt/RJ45 5-12L |
|
Housing Material |
Aluminum |
|
Housing Protection Grade |
IP20 |
|
Nominal Discharging current(8/20us) |
5kA |
|
Max. Discharging current(8/20us) |
10kA |
|
Limited Voltage(L-N) |
< 30v |
|
Limited Voltage(L-PE, N-PE)V |
< 90 |
|
Transmission Rate(bit/s) |
100M |
|
Insertion Loss |
< 0.5dB |
|
Impendence |
0.5 Omega |
|
Interface Mode |
RJ45 |
|
Ambient temperature |
-40' C~+85' C |
|
Ambient Humidity |
< 95% |
|
Dimension |
481x96x45 |
|
Weight(kg) |
2.09 |
